NI SCXI-1193 Multi channel RF Multiplexing Switch Module Controller

Frequency Range DC to over 500 MHz
Topologies Supported Quad 8×1 Multiplexer, Quad 4×1 Terminated Multiplexer, Dual 16×1 Multiplexer, Dual 8×1 Terminated Multiplexer, 32×1 Multiplexer, 16×1 Terminated Multiplexer, Independent
Input/Output Connectors 36 MCX Jacks for I/O; 2 SMB Jacks for Trigger
Categories:
contact qrcode

Need help?
Email: sales@fyplc.cn
Tel/WhatsApp: +86 173 5088 0093

Description

NI SCXI-1193 Multi channel RF Multiplexing Switch Module Controller

SCXI-1193-4

SCXI-1193

The NI SCXI – 1193 is designed to support industrial control systems where precise signal routing and high – frequency signal handling are essential. Whether it’s in a research laboratory conducting high – speed data acquisition experiments, a manufacturing plant monitoring various production parameters, or a telecommunications facility ensuring seamless signal transmission, this module fits right in.

Label Specification
Model Number SCXI – 1193
Brand National Instruments
Type High – Density Multiplexer Switch Module
Frequency Range DC to over 500 MHz
Topologies Supported Quad 8×1 Multiplexer, Quad 4×1 Terminated Multiplexer, Dual 16×1 Multiplexer, Dual 8×1 Terminated Multiplexer, 32×1 Multiplexer, 16×1 Terminated Multiplexer, Independent
Input/Output Connectors 36 MCX Jacks for I/O; 2 SMB Jacks for Trigger
Relay Type Electromechanical, Latching
Relay Contact Material Silver Palladium and Gold
Scan Rate Up to 100 operations per second
DC Power Requirements +5 VDC at 50 mA, +18.5 – +25 VDC at 170 mA, -18.5 – -25 VDC at 170 mA
Dimensions 1.2 x 6.8 x 7.8 inches (3.0 x 17.3 x 19.8 cm)
Weight 2 lb 2 oz (960 g)
Operating Temperature Range 0 °C to 50 °C
Storage Temperature Range -20 °C to 70 °C
Humidity Range 5% – 85% non – condensing
SCXI-1193-3

SCXI – 1193

The NI SCXI – 1193 has been meticulously engineered to offer several remarkable performance attributes. Its high – frequency capabilities, with a bandwidth extending up to over 500 MHz, make it an ideal choice for applications that demand the accurate handling of high – speed signals. This means that in scenarios where rapid data transfer and processing are crucial, such as in high – speed data acquisition systems, the module can keep pace without compromising on signal integrity.

SCXI-1193-2

SCXI – 1193

In terms of build quality, the NI SCXI – 1193 is a cut above the rest. It features a robust construction with electromechanical latching relays made of high – quality silver palladium and gold, ensuring long – lasting reliability. These relays are designed to withstand a large number of switching cycles, reducing the need for frequent replacements and minimizing downtime in industrial operations.
