PROSOFT PTQ-PDPMV1 Ethernet Communication Module

Input Voltage	24V DC (18–32V DC wide-range input)
Power Consumption	5W (typical operation, no external fan)
Operating Temperature	-40°C to +70°C (extended industrial grade)
Communication Rate	Profibus: Up to 12 Mbps; DeviceNet: Up to 500 kbps
Network Nodes	Supports up to 124 Profibus nodes; 64 DeviceNet nodes

Categories: OTHER

Need help?
Email: sales@fyplc.cn
Tel/WhatsApp: +86 173 5088 0093

Description
Reviews (0)

Description

PROSOFT PTQ-PDPMV1 Ethernet Communication Module

PTQ-PDPMV1

As a core enabler of industrial network interoperability, the PROSOFT PTQ-PDPMV1 is purpose-built to eliminate communication barriers between different protocols. Its primary role is to translate data between Profibus DP/V1 and DeviceNet, ensuring that devices from diverse manufacturers can operate in unison. Whether deployed in a high-speed assembly line, a complex PLC network, or a distributed control system (DCS), this gateway acts as a reliable bridge, facilitating bidirectional data flow while maintaining the integrity and speed required for critical control applications.

Label	Specification
Model Number	PTQ-PDPMV1
Brand	Prosoft Technology
Type	Profibus to DeviceNet Protocol Gateway
Supported Protocols	Profibus DP/V1 (Master/Slave), DeviceNet (Scanner/Adapter)
Input Voltage	24V DC (18–32V DC wide-range input)
Power Consumption	5W (typical operation, no external fan)
Operating Temperature	-40°C to +70°C (extended industrial grade)
Communication Rate	Profibus: Up to 12 Mbps; DeviceNet: Up to 500 kbps
Network Nodes	Supports up to 124 Profibus nodes; 64 DeviceNet nodes
Mounting Style	Din-rail or panel-mountable (compact design: 100mm x 80mm x 30mm)
Certifications	CE, UL 508, IEC 61000-6-2 (EMC compliance)
Configuration	Web-based interface via Ethernet (10/100 Mbps)
Diagnostic Features	LED status indicators, real-time error logging
Isolation	2.5 kV rms isolation between networks

PTQ-PDPMV1

The PROSOFT PTQ-PDPMV1 stands out for its ability to deliver seamless protocol conversion without compromising data integrity or speed. Its advanced processing engine ensures low-latency data translation, making it suitable for time-critical applications like motion control or real-time process monitoring. The gateway’s dual-role capability—functioning as both a Profibus master/slave and DeviceNet scanner/adapter—provides unparalleled flexibility, allowing it to adapt to diverse network topologies without additional hardware. Engineers appreciate its plug-and-play configuration, which simplifies setup through a user-friendly web interface, reducing commissioning time and minimizing the risk of configuration errors.

PTQ-PDPMV1

PROSOFT PTQ-PDPMV2 – An upgraded version with enhanced data throughput and support for newer Profibus profiles, ideal for large-scale industrial networks.

PROSOFT MVI56-PDPM – A modular gateway for Allen-Bradley ControlLogix systems, integrating Profibus with EtherNet/IP for hybrid setups.

PROSOFT DNet-PBMS – A compact standalone adapter for simple point-to-point Profibus-DeviceNet communication in small automation cells.

Siemens 6ES7158-0AD01-0XA0 – A compatible Profibus gateway for Siemens PLC environments, often used alongside the PTQ-PDPMV1 in multi-vendor systems.
