SCHENCK VEG20400 – Control Electronics for SCHENCK weighfeeders and process dosing lines

The SCHENCK-VEG20400 is a control/IO electronics module used in SCHENCK Process weighing and feeding systems. From my experience, it’s typically found as a replacement board in belt weighfeeders and loss-in-weight feeders where you need stable load cell conditioning, belt speed capture, and dependable analog/digital signaling back to the PLC or HMI. If you’re keeping legacy SCHENCK lines running—or standardizing spares across sites—this module helps you minimize downtime without re-engineering your cabinet.

Company’s Order Placement Process and Guarantees

• Warranty: 365 days
• Delivery: 1 week for in-stock; no more than one month at the latest
• Payment: 50% advance payment; full payment prior to delivery
• Express: FedEx, UPS, DHL

Key Features

• Load cell signal conditioning – Stable excitation and low-noise amplification for strain-gauge load cells, keeping zero and span drift under control.
• Encoder/pulse input for belt speed – Typically accepts a pulse or encoder input to compute mass flow with better repeatability.
• Analog output (4–20 mA) – Feeder setpoint or rate feedback to your PLC/DCS without extra converters.
• Digital I/O – Discrete inputs for interlocks and relay/solid-state outputs for alarms, feeder run/stop, or dosing permissives.
• RS‑485 connectivity – In many cases, integrates via Modbus RTU or SCHENCK-standard links for quick drop-in replacement.
• 24 VDC industrial supply – Common cabinet power, simplifying spares management across different lines.
• Cabinet/DIN-rail mounting – Fits standard control enclosures, which makes on-site swap straightforward for maintenance teams.
• Service-friendly calibration – Zero/span and rate checks can be performed with standard test weights or electronic simulation.

Technical Specifications

Application Fields

You’ll typically see the VEG20400 in continuous dosing and weighing applications where rate accuracy and uptime matter:

• Belt weighfeeders in cement and mining for clinker, limestone, ore, and coal dosing
• Loss-in-weight feeders for powders/granules in chemicals and specialty materials
• Food & grain handling lines where rate feedback and batching repeatability are critical
• Steel and power plants for fuel/flux feed control and inventory tracking

One thing I appreciate is how it slots into existing SCHENCK control architectures without forcing PLC changes—handy on brownfield sites with tight shutdown windows.

Advantages & Value

• Compatibility – Designed for SCHENCK systems, so wiring and calibration routines feel familiar to maintenance teams.
• Reduced downtime – Fast swap for failed boards; you keep the existing mechanics, load cells, and encoder.
• Stable measurement – Clean signal conditioning typically trims noise and drift in harsh environments.
• Cost control – Extends lifecycle of installed feeders without a full controls migration.
• Technical backing – We assist with parameter backups, on-site start-up tips, and wiring checklists when requested.

A maintenance supervisor at a cement mill mentioned they swapped a VEG20400 during a short line stop and were back in auto within an hour—no recipe changes, just a quick span check with test weights.

Installation & Maintenance

• • Cabinet & environment – Install inside an IP-rated control cabinet with ventilation; avoid conductive dust; keep ambient 0–50°C.
  • Grounding & shielding – Bond cabinet ground; use shielded cable for load cells and encoders; route power and signal separately.
  • Wiring – Observe 6‑wire load cell wiring where available (sense lines improve stability); verify encoder polarity and pulse factor.

• Calibration – Perform zero and span with certified test weights (or an electronic simulator when weights aren’t feasible); log parameters.
• Routine checks – Inspect terminals for looseness, clean dust quarterly, confirm 24 VDC supply ripple is within limits, and back up configuration.
• Firmware/config – Where applicable, keep firmware aligned with your installed base; note parameter revisions on maintenance records.
• Safety – Isolate 24 VDC power before servicing; verify lockout on feeder drives and interlocks before live testing.

Quality & Certifications

• CE compliant design; RoHS-conforming components where specified
• Manufactured under ISO 9001 quality systems (manufacturer level)
• UL/CSA considerations typically apply at the panel level; install in a certified cabinet when required
• Manufacturer’s warranty: 12 months (365 days) from delivery

If you’re matching against an existing installation, share a photo of the current board and the feeder nameplate. You might notice small revision differences by year, but the core signals—load cell, encoder, analog out, and RS‑485—tend to be consistent, which makes cross-site standardization a lot easier.
