SST 5136-DNP-PCI Network Interface Card Adapter Module Data Transmission Tool

The SST 5136-DNP-PCI is engineered with a clear focus on enabling robust communication based on the DNP3 protocol. DNP3, or Distributed Network Protocol 3, is widely recognized in the power and utility sectors for its reliability and efficiency in handling real-time data. This card is specifically tailored to operate within PCI (Peripheral Component Interconnect) – based systems, making it an ideal choice for industrial PCs and control servers. Its primary purpose is to enable seamless communication between field devices, such as sensors, actuators, and remote terminal units (RTUs), and the supervisory control and data acquisition (SCADA) systems that manage and monitor industrial processes. Whether it’s in a large-scale power plant, a water treatment facility, or an oil and gas pipeline network, the SST 5136-DNP-PCI plays a pivotal role in ensuring that data flows smoothly, allowing operators to make informed decisions and maintain optimal system performance.

Label	Specification
Model Number	SST 5136-DNP-PCI
Brand	SST (Schneider Electric)
Type	PCI – based DNP3 Communication Interface Card
Input Voltage	Derived from the PCI bus power supply
Power Consumption	Low – power design, typically ≤5W
Operating Temperature	0°C – 60°C
Storage Temperature	-40°C – 85°C
Communication Rate	Supports up to 115.2 kbps
Protection Class	N/A (operates within protected enclosures)
Mounting Method	Installs directly into a PCI slot of a compatible PC or server
Protocol Support	DNP3 protocol version 3.0, with support for both master and slave modes
Data Transmission	Enables reliable, real-time data transfer, including event-driven reporting
Certifications	Complies with industry standards such as CE, FCC, and RoHS

The SST 5136-DNP-PCI offers a range of functional strengths that make it stand out in the industrial communication landscape. Its support for both master and slave modes in the DNP3 protocol provides unparalleled flexibility. As a master, it can efficiently query and manage multiple slave devices, collecting data from various field sensors and devices across an industrial network. Conversely, in slave mode, it can respond promptly to commands from a master system, ensuring seamless integration with existing SCADA and control systems. This dual – mode operation allows for highly adaptable communication setups, catering to the diverse needs of different industrial applications.​

The card’s design emphasizes reliability and durability. With a low – power consumption profile, it can operate continuously without generating excessive heat, reducing the risk of overheating – related failures. Its ability to function within a wide temperature range, from 0°C to 60°C during operation and -40°C to 85°C during storage, ensures that it can withstand the varying environmental conditions often encountered in industrial settings. Additionally, the SST 5136-DNP-PCI is engineered to be highly resistant to electrical noise and interference, which are common in industrial environments. This resilience ensures that data is transmitted accurately and consistently, minimizing the occurrence of data errors and ensuring the integrity of the communication process.
​

Installation and integration of the SST 5136-DNP-PCI are straightforward. Its PCI form factor allows for easy insertion into compatible industrial PCs and servers, eliminating the need for complex external interfaces or additional adapters. Once installed, the card can be quickly configured using SST’s dedicated software tools, which provide an intuitive interface for setting up communication parameters, such as baud rate, data format, and device addressing. This simplicity in installation and configuration not only saves time during deployment but also reduces the potential for errors, making it accessible even to users with limited technical expertise.
