TRICONEX 3000470-510 Digital Input/Output Distributed Control System Module
3000470-510
The TRICONEX 3000470-510 has been engineered to deliver exceptional signal integrity in harsh industrial environments, where electromagnetic interference and voltage transients are common. Its robust design includes continuous overvoltage protection up to 150V DC, preventing damage from accidental power surges that could compromise safety system performance. The module’s precision signal conditioning ensures accurate conversion of analog sensor data, providing the Tricon controller with reliable input for critical safety logic decisions.
|
Label
|
Specification
|
|
Model Number
|
TRICONEX 3000470-510
|
|
Brand
|
TRICONEX (Schneider Electric)
|
|
Type
|
Analog Input Terminal Panel Module
|
|
Input Voltage
|
24V DC (±10%)
|
|
Signal Input Range
|
0-5V DC / 0-10V DC
|
|
Operating Temp
|
-40°C to 65°C (-40°F to 149°F)
|
|
Communication Method
|
Tricon Backplane Bus
|
|
Mounting
|
Rack-mounted (Tricon Chassis Compatible)
|
|
Weight
|
Approximately 1.5 kg (3.3 lbs)
|
|
Certifications
|
TÜV, SIL 3 (IEC 61508), ATEX, IECEx
|
|
Dimensions
|
Approximately 150mm × 100mm × 80mm (5.91″ × 3.94″ × 3.15″)
|
|
IP Rating
|
IP20 (When Installed in Enclosed Chassis)
|
|
Protocols Supported
|
Tricon Proprietary, Modbus (via system integration)
|
|
Input Protection
|
150V DC / 115V AC continuous overvoltage protection
|
TRICONEX 3700A – Analog input module with three independent channels for 0-5V signals, often paired with the TRICONEX 3000470-510 in complex SIS. TRICONEX 3006 – Compact Tricon controller that integrates seamlessly with the 3000470-510 terminal panel for small to medium safety systems. TRICONEX 3510 – Pulse input module that complements the TRICONEX 3000470-510 by handling flow meter signals in safety loops. TRICONEX 3004 – Communication module enabling Ethernet connectivity between the Tricon system and SCADA, enhancing data visibility from the 3000470-510. TRICONEX 4000098-510 – Redundant power supply that ensures uninterrupted operation of the TRICONEX 3000470-510 and associated I/O modules. TRICONEX 3200 – Digital input module that works alongside the 3000470-510 to provide mixed-signal safety monitoring. TRICONEX 3625 – Analog output module that receives control signals from the Tricon controller, forming a complete loop with the TRICONEX 3000470-510.
