TRICONEX 3604E Digital Output I/O Communication Control Module
Installing the TRICONEX 3604E requires adherence to TRICONEX chassis mechanical keying guidelines: align the module’s built-in key with the designated digital output slot in the chassis, then engage the locking lever until it clicks to ensure secure backplane connectivity. When wiring to actuators, verify that 24V DC connections match the module’s terminal markings (e.g., “OUT+” for positive output, “GND” for ground) to avoid reverse polarity damage; use twisted-pair cables for output signals and connect cable shields to the module’s dedicated grounding terminal to reduce electromagnetic interference. The TRICONEX 3604E relies on passive cooling, so maintain a 50mm clearance above and below the module to prevent overheating in enclosed chassis.
|
Label
|
Specification
|
|
Model Number
|
TRICONEX 3604E
|
|
Brand
|
TRICONEX (Schneider Electric)
|
|
Type
|
16-Channel Isolated Digital Output Module
|
|
Output Signal
|
24V DC Discrete (Sink/Source Configurable)
|
|
Output Channels
|
16 Independent, Galvanically Isolated Channels
|
|
Input Voltage
|
24V DC (±15%)
|
|
Operating Temp
|
-40°C to 70°C (-40°F to 158°F)
|
|
Communication Method
|
Tricon Backplane Bus
|
|
Mounting
|
Rack-Mounted (TRICONEX Chassis Compatible)
|
|
Weight
|
Approximately 1.3 kg (2.87 lbs)
|
|
Certifications
|
TÜV, SIL 3 (IEC 61508), ATEX, IECEx, UL 61010
|
|
Dimensions
|
145mm × 98mm × 78mm (5.71″ × 3.86″ × 3.07″)
|
|
IP Rating
|
IP20 (When Installed in Enclosed Chassis)
|
|
Output Protection
|
Short-Circuit Protection (Up to 2A Per Channel)
|
|
Fault Diagnostics
|
Channel-Level LED Indicators + Backplane Alerts
|
TRICONEX 8307A – 16-channel digital input module that pairs with the TRICONEX 3604E to form complete discrete I/O loops (monitoring sensors via 8307A, controlling actuators via 3604E).
TRICONEX 3006 – Compact Tricon controller that seamlessly integrates the TRICONEX 3604E for small to medium-scale SIS applications (e.g., tank farm safety control). TRICONEX 3004 – Ethernet communication module that enables SCADA systems to monitor TRICONEX 3604E output status for remote safety oversight.
TRICONEX 4000098-510 – Redundant power supply ensuring stable 24V DC to the TRICONEX 3604E and associated I/O modules.
TRICONEX 3626X – 4-channel analog output module, used alongside the TRICONEX 3604E in mixed-signal safety systems (e.g., combining discrete valve control with analog pump speed regulation).
TRICONEX 8111 – 8-channel analog input module that complements the TRICONEX 3604E by monitoring process variables (e.g., pressure) that trigger discrete actuator actions. TRICONEX 3200 – 16-channel digital input module, an alternative to the 8307A for pairing with the TRICONEX 3604E in high-density discrete systems.
