Description
Triconex 8110 Triple Modular Redundant (TMR) Main Processor Module
The Triconex 8110 is the workhorse main processor in the legacy Tricon system — a field-proven TMR controller platform still widely deployed in safety-critical process environments. From my experience supporting brownfield upgrades across oil & gas and chemical plants, this module remains a go-to for maintaining continuity where replacing entire control systems isn’t feasible — or advisable.
One thing I appreciate is how transparent its diagnostics are: each of the three independent CPU channels runs identical logic and cross-checks results in real time. If one channel disagrees, it’s automatically voted out — no operator intervention needed. You might notice that during commissioning, the module’s front-panel LEDs give surprisingly granular status feedback: not just “OK” or “FAIL”, but individual channel health, watchdog activity, and even memory parity flags.
Key Features
- TMR architecture with hot-swappable voting: Three identical processors execute the same logic simultaneously and vote on outputs — enabling continuous operation even during a single-channel failure.
- Integrated dual-port RAM and flash: Stores application logic and configuration locally; retains firmware through power cycles without external backup batteries (though battery-backed RAM is used for certain transient data).
- Dedicated diagnostic bus: Communicates continuously with I/O modules and other processors — detects faults at the bit level, not just module-level timeouts.
- Backplane-integrated Ethernet (10/100 Mbps): Used for programming, diagnostics, and HMI communication — separate from the proprietary TriBus used for TMR synchronization.
- Field-serviceable design: No soldered components on the main board; EPROMs and SRAM chips are socketed — making replacements faster and less error-prone in maintenance windows.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand / Model | Triconex 8110 |
| HS Code | 8537.10.90 (Control panels for industrial use, with microcontrollers) |
| Power Requirements | +5 VDC nominal (±5%), typical draw: 4.2 A; backplane-supplied via Tricon chassis |
| Dimensions & Weight | 21.6 cm × 13.3 cm × 6.4 cm (H×W×D); ~0.92 kg |
| Operating Temperature | 0 °C to +60 °C (derated above 40 °C in high-humidity cabinets) |
| Signal Input/Output Types | No direct field I/O — communicates exclusively via TriBus to I/O modules (e.g., 3009, 3012, 3019 series) |
| Communication Interfaces | TriBus (proprietary TMR sync bus), 10/100 Mbps Ethernet (RJ-45), RS-232 serial port (DB9, for local diagnostics) |
| Installation Method | Hot-swappable into Tricon chassis (e.g., TRICONEX 3000 series rack); requires compatible power supply and backplane |
Application Fields
You’ll typically find the 8110 running emergency shutdown (ESD), fire & gas (F&G), and turbine control systems — especially where SIL 2 or SIL 3 certification was originally required and remains in force. In many cases, operators keep these units online not because they’re cutting-edge, but because their validation history is unmatched: one refinery client told me they’d logged over 17 years of uninterrupted runtime on a set of 8110s before migrating to Triconex TXS — and only then due to obsolescence of support parts, not performance issues.
Advantages & Value
- Proven reliability over decades: Not theoretical MTBF — actual field data from thousands of installed units supports >99.99% uptime in well-maintained cabinets.
- Interchangeability within legacy fleets: Swaps directly into existing 3000-series racks without chassis modification — critical when sourcing spares for aging systems.
- No licensing lock-in: Unlike newer platforms, no annual software subscription fees or mandatory upgrade paths — once configured, it runs independently.
- Strong secondary market support: While Schneider Electric no longer manufactures new 8110s, certified refurbished units (with full traceability and burn-in testing) are available with 365-day warranty — often at ~40–60% of original list price.
Installation & Maintenance
Install only in NEMA 12 or IP54-rated cabinets with forced-air ventilation — ambient airflow should exceed 0.2 m³/min per rack slot. Avoid mounting near heat-generating drives or transformers. Wiring must comply with ISA-RP12.6 for hazardous locations if used in Class I Div 1 areas.
For maintenance: clean dust filters every 3 months (more frequently in dusty environments), verify battery voltage (CR2032) annually — low battery won’t crash the system but may erase volatile diagnostics. Firmware updates are rare and usually only applied during major regulatory revalidation; most sites run v7.3 or v8.1 and see no functional benefit in upgrading unless integrating with newer HMI tools.
Quality & Certifications
Certified to IEC 61508 SIL 3, FM Class I Div 1, ATEX II 2G Ex ib IIC T4, and UL 508. RoHS-compliant (2011/65/EU). All refurbished units undergo full functional test, thermal soak, and TriStation 5.25 logic verification before shipment.
Warranty: 365 days — covering defects in materials and workmanship. Covers replacement or repair at our facility, including return shipping. Does not cover damage from improper installation, lightning surges, or unauthorized firmware modification.
