Woodward 8444-1067 Digital Governor Controller
8444-1067
The core purpose of the Woodward 8444-1067 is to maintain turbine speed within tight tolerances, even under fluctuating load conditions. By continuously monitoring speed feedback from magnetic pickups or proximity probes, the governor adjusts the turbine’s fuel supply, steam valves, or hydraulic actuators in real time to counteract load changes. This ensures seamless synchronization with electrical grids in power generation applications or precise speed control for mechanical drives in industrial processes. The result is improved efficiency, reduced wear on turbine components, and enhanced system reliability.
| Label |
Specification |
| Model Number |
8444-1067 |
| Brand |
Woodward |
| Type |
Electronic Speed Governor (ESG) |
| Input Power |
10-30 V DC (wide-range compatibility) |
| Speed Control Range |
0-15,000 RPM (configurable for specific turbine models) |
| Control Accuracy |
±0.1% of rated speed (under steady-state conditions) |
| Communication |
RS-485 (Modbus RTU), analog I/O (4-20 mA, 0-10 V) |
| Operating Temperature |
-40°C to 85°C (extreme environment rating) |
| Mounting |
DIN-rail or panel-mountable (compact design for control cabinets) |
| Weight |
~1.2 kg |
| Certifications |
CE, UL, RoHS, compliant with ISO 9001 |
| Dimensions |
178 mm (H) × 102 mm (W) × 152 mm (D) |
| Redundancy Features |
Optional dual-channel configuration for critical applications |
8444-1067
The 8444-1067 leverages Woodward’s proprietary Adaptive Gain Scheduling and Load Anticipation algorithms to deliver unmatched speed regulation. Adaptive Gain Scheduling adjusts control parameters based on real-time operating conditions, ensuring consistent performance across the entire speed range. Load Anticipation predicts changes in turbine load (e.g., when a generator connects to the grid) and pre-adjusts the actuator to minimize speed droop, reducing transient overshoot and improving stability. For example, in a combined-cycle power plant, the governor can seamlessly handle sudden load increases from grid demand, maintaining frequency stability within milliseconds.
Built to withstand harsh environments, the 8444-1067 features a rugged metal enclosure and conformal coating to protect against moisture, dust, and vibration. Its wide operating temperature range (-40°C to 85°C) makes it suitable for both indoor control rooms and outdoor installations, such as gas compression stations in arctic or desert climates. The module’s dual-channel redundancy option (when configured) further enhances reliability in mission-critical applications, allowing for hot-swappable maintenance without interrupting turbine operation.
The governor’s intuitive interface, accessible via Woodward’s
TurboSet II software, simplifies configuration and diagnostics. Engineers can customize parameters such as speed droop, acceleration limits, and alarm thresholds through a graphical user interface (GUI), reducing commissioning time. The
8444-1067 also supports remote monitoring via Modbus RTU, enabling operators to track turbine performance in real time from a central SCADA system. This is particularly valuable in distributed power generation networks, where multiple turbines must be managed remotely.
8444-1067
In a 50 MW steam turbine power plant, the Woodward 8444-1067 ensures stable grid synchronization by maintaining turbine speed at 3,000 RPM (50 Hz) or 3,600 RPM (60 Hz) with ±0.1% accuracy. During load shedding events (e.g., a sudden loss of grid demand), the governor’s fast-acting Load Rejection feature rapidly closes the steam inlet valve to prevent overspeeding, protecting the turbine from damage. This capability is critical for maintaining grid stability and avoiding cascading failures.
In a natural gas pipeline compressor station, the
8444-1067 controls a gas turbine-driven compressor to maintain a constant discharge pressure of 1,500 PSIG. As pipeline demand fluctuates, the governor adjusts the turbine’s fuel flow to match compressor speed requirements, ensuring uninterrupted gas flow while optimizing fuel efficiency. The module’s ability to operate in high-temperature environments (up to 85°C) is essential for reliable performance in compressor shelters with limited ventilation.
8444-1067
In a paper mill, the 8444-1067 manages a steam turbine driving a high-speed paper machine. The governor’s precise speed control (±0.1%) is critical for maintaining consistent paper thickness and quality, as even minor speed variations can cause defects in the paper web. The module’s analog I/O interfaces also enable integration with the mill’s process control system, allowing operators to adjust turbine speed in real time based on paper production rates.
