WOODWARD PEAK200-HVAC (8200-1501) – Digital Speed/Actuator Controller for HVAC Fans, Blowers, and Engine-Driven Air-Handling Systems

The WOODWARD PEAK200-HVAC 8200-1501 is a compact digital governor and actuator controller typically used to keep rotary equipment—fans, blowers, small compressors, and engine-driven HVAC units—running at a stable, precise speed. From my experience, this model is chosen when you need tight isochronous or droop speed control, clean transitions, and a reliable current drive for Woodward electric actuators without overcomplicating the panel. You might notice that it fits well in retrofit scenarios where older mechanical governors need a robust, low-maintenance upgrade.

Company’s Order Placement Process and Guarantees

• Warranty: 365 days
• Delivery: 1 week for in-stock items; no more than one month at the latest
• Payment: 50% advance payment, full payment for delivery
• Express options: FedEx, UPS, DHL

Key Features

• Digital speed control (isochronous or droop): Keeps fan or blower RPM steady under varying load; tuning is straightforward in most cases.
• Magnetic pickup speed input: Works with standard MPU sensors typically used on engine flywheels and rotating shafts.
• Actuator current drive: Directly drives Woodward electric actuators (commonly 0–200 mA current output), reducing interface hardware.
• Analog setpoint and discrete commands: Accepts a 4–20 mA or 0–5 V setpoint plus raise/lower or run/stop inputs for quick on-site adjustments.
• Soft start and acceleration ramps: Smoother fan starts help protect belts, couplings, and bearings—especially valuable in HVAC air handlers.
• Alarm/relay output: A simple status output typically used for panel annunciation or system interlocks.
• Service/configuration port: Local service access (commonly RS‑232) makes commissioning faster.
• Rugged operating range: Built for industrial control cabinets with wide temperature tolerance.

Technical Specifications

Application Fields

In many cases the PEAK200-HVAC is used on:

• AHUs and large ventilation fans driven by gas/diesel engines in remote facilities
• Industrial blowers for dust collection, furnaces, or process air where stable RPM is critical
• Retrofits of older mechanical governors on small compressors or fan drives
• Packaged engine-driven HVAC units where simple, reliable speed control is preferred over full PLC complexity

“After replacing a worn mechanical governor, the PEAK200 stabilized our fan speed within minutes of tuning, and nuisance trips basically disappeared.” — Maintenance Supervisor, food processing plant

Advantages & Value for Procurement

• Reliability that reduces downtime: Solid-state control with proven Woodward actuator drive stage; fewer mechanical wear parts.
• Compatibility with installed base: Works with common Woodward actuators and MPU sensors, which typically simplifies retrofits and spares.
• Lower lifecycle costs: Stable control helps avoid belt slippage, bearing stress, and overspeed events—saving parts and labor over time.
• Straightforward commissioning: Service-port tuning and clear I/O reduce on-site hours; less dependency on custom PLC logic.
• Support and documentation: Widely deployed, which means technicians are usually familiar with setup and typical fault patterns.

Installation & Maintenance

• Cabinet standards: Mount in a dry, ventilated industrial control cabinet; keep away from heat sources and high-vibration zones.
• Power and grounding: Provide a clean 24 VDC supply (18–32 VDC range). Use proper chassis grounding and observe reverse-polarity protection practices.
• Wiring: Use shielded, twisted-pair cable for the MPU input; route low-level signals away from motor leads and contactors. Tighten screw terminals to the specified torque.
• Commissioning: Set base speed, choose isochronous or droop mode, then tune PID gains with the load you expect in operation. Enable soft-start to protect the drive.
• Routine maintenance: Periodically check connectors and grounding, clean dust from the cabinet, verify setpoint/feedback signals, and back up configuration via the service port.
• Safety: Lock out power before servicing. Confirm actuator travel is clear and interlocks are functional before live tests.

Common Supporting Components

• WOODWARD magnetic pickup sensors for flywheel speed sensing
• WOODWARD electric actuators (e.g., ProAct series, EG/EPG family) for throttle or vane control
• Engine throttle bodies or fuel racks compatible with Woodward actuator linkage kits
• Shielded signal cabling and panel power conditioning (24 VDC)

Quality & Certifications

• Manufactured under ISO 9001 quality systems
• CE compliant; UL/cUL recognition typically available for control equipment
• RoHS compliant design
• Manufacturer’s standard warranty: 12 months (365 days)

Note: Specifications above reflect typical PEAK200-HVAC behavior and common field configurations for the 8200-1501 variant. If you’re matching an existing actuator or MPU, share the exact actuator model and sensor details, and I’ll confirm drive current, input levels, and any wiring nuances before shipment.
