YOKOGAWA DR1030B60 Hybrid Chart Recorder for Multi‑Channel Process Monitoring

The YOKOGAWA DR1030B60 is a compact hybrid chart recorder designed for dependable, multi‑channel data logging in control panels and equipment skids. From my experience, the DR series is typically chosen when plants need hard‑copy traceability and on‑screen diagnostics in one unit—no PC required. It seems to be a good fit for temperature, pressure, and general analog signals in utilities, OEM machines, heat treatment, and water treatment systems, where a paper record is still a compliance or QA requirement.

Company’s Order Placement Process and Guarantees

• Warranty: 365 days
• Delivery: 1 week if in stock; no more than one month at the latest
• Payment: 50% advance payment; full payment prior to delivery
• Express options: FedEx, UPS, DHL

Key Features

• Hybrid recording (paper + digital display) – Provides immediate paper traceability while keeping clear on-screen values and alarms.
• Universal inputs – Typically supports DC voltage (mV/V), current (via shunt), thermocouples, and RTDs for mixed process signals on one device.
• Multi‑channel logging – Suitable for multi-point temperature or pressure monitoring in compact panels.
• Alarm handling – High/low limit alarms with optional relay outputs to annunciate events or interlock external devices.
• Panel‑mount build – 144 × 144 mm class front panel format integrates cleanly into standard control cabinets.
• Industrial communications – RS‑232C/RS‑485 are commonly available; some builds include Ethernet on certain options (varies by configuration).
• Operator‑friendly front panel – Simple navigation and clear indicators reduce setup time and everyday use errors.

Technical Specifications

Application Fields

You might notice that the DR1030B60 is often specified where a physical audit trail is still needed or simply preferred. Typical use cases include:

• Heat treatment ovens and environmental chambers – temperature profiling with hard‑copy records for QA.
• Water and wastewater panels – logging pH, flow (via 4–20 mA), and chlorine signals in a single box.
• Food & beverage – HACCP‑friendly paper records of critical temperatures.
• Power and utilities – transformer/auxiliary temperature monitoring with event alarms.
• OEM machinery – compact panel recorder for factory acceptance and warranty documentation.

A maintenance manager at a packaging line told us they like the DR format because operators “get the paper in hand after every batch,” which cut their dispute time during QA checks.

Advantages & Value

• Reliability – YOKOGAWA recorders are known for stable inputs and long service life; downtime tends to be low in most cases.
• Compatibility – Works with common industrial signals and fits standard 144 mm panel cutouts, easing retrofit projects.
• Cost control – Hybrid recording removes the need for a PC and printer on the line; consumables are predictable (paper).
• Supportability – Clear model code and modular options make spare parts and replacements straightforward.

Installation & Maintenance

• Panel/Cabinet – Mount on a rigid panel (144 × 144 mm class). Provide 50–100 mm rear clearance for wiring and heat dissipation, with steady ventilation.
• Power & Grounding – Use a clean 100–240 VAC source; earth ground the chassis. For low‑level mV signals, route shielded pairs separately from mains and drives.
• Wiring – Follow terminal labeling. Use external shunts for 4–20 mA when required by the input board. Confirm thermocouple polarity and RTD 2/3/4‑wire settings.
• Safety – De‑energize before servicing. Verify insulation resistance if installed in high‑humidity cabinets.
• Routine care – Replace/stock thermal chart paper, clean intake vents, and check print quality. Calibrate inputs on your site interval (typically 12–24 months). Keep configuration backups.
• Firmware/configuration – For units with communication options, keep configuration files backed up; apply firmware updates when available for your build code.

Quality & Certifications

• CE compliant; UL/cUL listing is typical for DR series variants
• RoHS conformity where applicable to the production year
• Manufacturer’s warranty support, with our 365‑day warranty provided on supply

Related Accessories & Supporting Components

• Thermal chart paper (100 mm width class)
• Panel mounting brackets and gasket set
• External 250 Ω shunt resistors for 4–20 mA inputs (if required)
• Terminal blocks and cable labels for multi‑channel wiring
• Spare fuses and front‑panel protective film

If your application needs a specific DR1030 option set (for example, exact input board mix or communications), share the full build code from the nameplate and we’ll match it one‑for‑one or propose a compatible equivalent.
