330101-39-47-10-02-05 Bently Nevada 3300 XL 8mm Eddy Current Proximity Probe

1. Full Model Code Breakdown

330101-39-47-10-02-05

1. 330101: Base model = 3300 XL 8mm standard probe, 3/8-24 UNF mounting thread
2. 39: Probe housing length = 3.9 inches
3. 47: Unthreaded barrel extension length = 4.7 inches
4. 10: Total integrated cable length = 1.0 meter
5. 02: Connector type = Miniature ClickLoc coaxial plug (standard triaxial 75Ω)
6. 05: Certification option = ATEX / IECEx / CSA hazardous area explosion-proof approval

2. Core Technical Specifications

• Brand: Bently Nevada (Baker Hughes)
• Detection Principle: Eddy current non-contact displacement sensing
• Probe Tip Diameter: 8mm
• Linear Measuring Range: 2.0 mm (80 mils), Scale Factor 200 mV/μm
• Output Signal: DC voltage -1 V ~ -17 V proportional to gap distance
• Thread Specification: 3/8-24 UNF male stainless steel thread
• Housing Material: AISI 303/304 stainless steel; Tip material: PPS high-temperature plastic
• Temperature Range: Operating -52°C ~ +177°C, Storage -62°C ~ +350°F
• Cable Parameter: 75Ω triaxial FEP insulated cable, non-armored standard design
• Electrical Index: Coil resistance 7.59Ω ±0.5Ω, capacitance 21.3pF/ft
• Certifications: API 670 compliant, ATEX/IECEx/CSA for Class I Div 2 hazardous zones
• Matching System: Must pair with 3300 XL Proximitor Sensor (signal converter) + extension cable to form complete vibration monitoring loop
•

3. Product Overview

The 330101-39-47-10-02-05 is a high-temperature extended-barrel eddy current proximity probe belonging to Bently Nevada flagship 3300 XL series, the industry standard for critical rotating machinery protection.

It measures radial shaft vibration, axial thrust position, shaft eccentricity and Keyphasor rotational speed signal without touching the rotating metal shaft. The extra-long 4.7-inch unthreaded barrel is designed for deep bearing housing installation, solving installation space limitations on large steam turbines, centrifugal compressors, gas turbines and heavy-duty pumps in power plants, refineries and petrochemical facilities.
