ABB 1VCR000993G0002 Auxiliary Power Supply Board

Technical Specifications

• Product Model: 1VCR000993G0002
• Brand: ABB
• Warranty: One Year
• Input Power: Wide‑range AC auxiliary input for vacuum‑contactor / switch‑gear control‑circuit power supply board
• Output: Multiple regulated DC auxiliary supply rails for internal control‑electronics
• Operating Temperature: ‑25 °C ~ +55 °C
• Storage Temperature: ‑40 °C ~ +85 °C
• Response Time: Power‑supply transient‑response for switch‑gear control‑circuit load‑variation
• Protection Class: IP20 printed‑circuit‑board assembly inside switch‑gear cabinet
• Accuracy Class: Switch‑gear auxiliary power‑supply regulation grade
• Output Frequency: Not applicable
• Protection Features: Over‑voltage, over‑current, short‑circuit built‑in protection circuits
• System Compatibility: ABB medium‑voltage vacuum‑contactor control‑circuit accessory board
• Diagnostics: Power‑good and fault‑status LED indicators on PCB assembly
• Humidity: 5‑95 % RH non‑condensing
• Weight: 0.58 kg
• Dimensions: Standard switch‑gear‑internal PCB assembly footprint
•

Product Overview

1VCR000993G0002 is ABB auxiliary power‑supply printed‑circuit‑board assembly, designed as control‑circuit accessory for medium‑voltage vacuum‑contactor units. It converts AC auxiliary‑mains input into multiple stable regulated DC supply rails for internal contactor control‑logic, monitoring‑circuit and interlock‑electronics inside switch‑gear cubicles. Multiple built‑in fault‑protection mechanisms improve reliability under substation‑grid‑disturbance conditions. Surplus and refurbished tested spare board for medium‑voltage switch‑gear‑cabinet maintenance‑projects.

Application Notes

‑ Strict ESD anti‑static handling required during PCB replacement inside energized‑safe switch‑gear environment. ‑ Confirm auxiliary‑mains voltage setting before power‑on. ‑ Verify all DC output rail voltages after board swap‑out. ‑ Typical deployment: MV vacuum‑contactor auxiliary‑power‑board spare‑part stocking.
