ABB 5SHX1060H0003 – Reverse Conducting IGCT Power Semiconductor Module

Product Overview

5SHX1060H0003 is a high‑power reverse‑conducting integrated gate‑commutated thyristor module for medium‑voltage power converters. It combines fast switching performance with an integrated freewheeling diode to deliver efficient four‑quadrant power conversion. This semiconductor component serves as the core power switch for large industrial drives and static reactive power compensation equipment, preventing costly production downtime when power stage hardware fails.

Technical Specifications

• Brand: ABB
• Model: 5SHX1060H0003
• Warranty: One Year
• Condition: 100% New & Original
• Device Type: RC‑IGCT power semiconductor
• Operating Temp: ‑40 °C ~ +125 °C (junction temperature)
• Mounting: Liquid‑cooled power stack assembly

Application Scenarios

• Offshore Oil & Gas Platform: Medium‑voltage variable‑speed drive power switch for large compressors
• Wind Power Converter Cabinet: High‑power switching element for megawatt‑class wind turbines
• Mining Hoist System: Spare power module for heavy‑duty mine winder converters
