1. Product Title
ABB 802A001B-1 – ACS800 Inverter Internal Interface Control Board
2. Product Overview
The 802A001B-1 is a genuine internal auxiliary printed circuit board specially designed for ABB ACS800 series multidrive and single drive variable frequency systems. It acts as an intermediate signal transfer and secondary logic coordination unit inside the inverter cabinet, responsible for distributing control power, collecting temperature feedback signals from power modules, transmitting fault alarm codes, and realizing electrical interlock between the main CPU board and peripheral functional subassemblies. Equipped with built-in surge suppression components and EMC filtering circuits, 802A001B-1 effectively mitigates high-frequency electromagnetic interference generated by IGBT power units and rectifier bridges, stabilizes the internal signal loop of the drive, and ensures accurate overheat protection, phase loss detection and fault self-diagnosis during continuous heavy-load operation. It serves as an essential spare part for repairing aging ACS800 inverters, eliminating sporadic fault trips and restoring full rated performance of large variable-speed driving equipment.
3. Technical Specifications
- Brand: ABB
- Model: 802A001B-1
- Warranty: One Year
- Condition: 100% New & Original
- Applicable Series: ABB ACS800 single drive and multidrive inverter assemblies
- Core Function: Internal power distribution, temperature signal acquisition, fault signal transmission, auxiliary interlock logic
- PCB Coating: Conformal coated circuit board for dust and moisture resistance
- Anti-Interference Design: Onboard EMC filter, overvoltage and short-circuit protection circuits
- Mounting Method: Fixed plug-in installation inside the ACS800 drive cabinet
- Operating Temperature: -10°C ~ +70°C
- Storage Temperature: -40°C ~ +85°C
- Environmental Resistance: Tolerates cabinet vibration, oil mist and slight corrosive gas in industrial sites
4. Application Scenarios
- Thermal Power Plant Auxiliary Equipment Maintenance: Used as replacement spare board for ACS800 drives controlling boiler induced draft fans, forced draft fans and feed water pumps, resolving drive internal signal communication failures and abnormal overheating alarms.
- Metallurgy & Mining Heavy Machinery: Applied to overhaul ACS800 inverters for rolling mill main drives, large belt conveyors and mine hoist systems, guaranteeing stable variable torque control under harsh heavy-duty working conditions.
- Oil & Gas Petrochemical Production Lines: Deployed for repairing frequency converters of large centrifugal compressors, process pumps and agitators in refineries, reducing unplanned production shutdown caused by drive control board degradation.
