ABB CI522A‑AF100 Fieldbus Interface Module

1. Product Title

ABB CI522A‑ AF100 S800 I/O Interface Module

2. Product Overview

The CI522A is an AF100 fieldbus interface module for ABB Advant control systems, establishing high‑speed communication between the controller and distributed S800 I/O racks. CI522A supports redundant bus operation to improve system availability for critical process applications. It handles cyclic I/O data exchange and module diagnostic reporting, translating controller commands to field‑level signal hardware. Front‑panel LED indicators simplify on‑site troubleshooting of bus faults and module status. Hot‑swap capability allows spare‑part replacement while the rest of the automation system remains operational.

3. Technical Specifications

• Brand: ABB
• Model: CI522A
• Warranty: One Year
• Condition: 100% New & Original
• Input/Output: AF100 fieldbus port for S800 I/O racks
• Communication: ABB AF100 fieldbus; supports redundant bus topology
• Power Supply: 24 VDC
• Operating Temp: ‑20 °C ~ +60 °C
• Dimensions/Weight: 265 × 120 × 27 mm; approx. 0.2 kg
• Mounting: Rack‑mount for ABB controller chassis
• Compatibility: ABB Advant 800M control system, S800 I/O series
•

4. Application Scenarios

• Process Industry Distributed I/O System: The CI522A acts as fieldbus gateway connecting central controllers to geographically dispersed S800 I/O racks in chemical and pulp‑and‑paper plants.
• Power Plant Auxiliary Control Cabinets: Deploys redundant AF100 links to collect field signals from turbine auxiliary and boiler‑auxiliary I/O nodes.
• Large‑Scale Plant Expansion Projects: Used for adding distributed I/O racks without major modification to existing Advant control hardware.
