Description

Detailed Technical Spec Sheet

• Brand: Allen‑Bradley (Rockwell Automation)
• Model: 140M-I8E-D10E
• Series: 140M Motor Protection Circuit Breaker
• Frame Size: I Frame
• Poles: 3-Pole
• Condition: Brand New Original
• Stock: In Stock Immediately
• Delivery Time: Shipped within 3 working days after payment confirmation
• Warranty: 12-month full functional warranty
• Thermal Adjustment Range: 80 A – 100 A
• Magnetic Trip Setting: Fixed 13 × rated In
• Trip Class: Class 10 overload protection
• Rated Operating Voltage: 480Y/277 VAC, 50/60 Hz; max 690V
• Short-Circuit Breaking Capacity: 65kA @ 480V, 30kA @ 600V
• Terminal Fitting: Factory fitted stainless steel lugs (#14–1/0 wire)
• Protection Standard: UL 489, UL 508, IEC 60947-4-1, CE, cULus certified
• Enclosure Rating: IP2X cabinet interior installation
• Operating Ambient Temperature: -20°C ~ +60°C
• Mechanical Life: 10,000 on/off operation cycles
• Installation: Standard DIN rail or panel mounting inside motor control centers
• Application: Conveyors, pumps, fans, compressors, packaging machine three-phase motor overload & short-circuit protection
•

SEO Main Description Paragraph

The Allen‑Bradley 140M-I8E-D10E is a robust I-frame three-pole motor protection circuit breaker designed to safeguard medium-current industrial three-phase motors. This 140M-I8E-D10E unit features an adjustable thermal trip spanning 80A to 100A paired with fixed 13×In instantaneous magnetic short-circuit trip, delivering reliable Class 10 overload protection to avoid motor burnout during heavy load fluctuations. Complying with global UL and IEC industrial safety standards, the 140M-I8E-D10E provides high short-circuit interrupt capacity to stabilize motor control center operation under power fault conditions. Pre-equipped with stainless steel terminal lugs simplifies fast field wiring for maintenance engineers and automation integrators. Every Allen‑Bradley 140M-I8E-D10E undergoes complete overload and short-circuit function testing prior to shipment, supported by instant spot stock and long-term warranty to cut equipment downtime for factory motor control cabinet retrofits and spare part replacement.
