ALLEN BRADLEY 709‑CAB SER‑P Full‑Voltage Motor Starter

Technical Specifications

• Product Model: 709‑CAB SER P
• Brand: Allen‑Bradley Rockwell Automation
• Warranty: One Year
• Function: Bulletin 709 NEMA full‑voltage non‑reversing motor starter
• NEMA Size: Size 0
• Rated Voltage: 600 VAC max for three‑phase motor load
• Integrated Protection: Bimetallic thermal overload relay for motor overload protection
• Auxiliary Contacts: 1NO +1NC auxiliary contact set
• Coil: AC control coil, SER‑P series version
• Mechanical Life: Over 10 million operating cycles
• Mounting: Panel‑mount open‑type starter assembly
• Operating Temperature: 0 °C ~ +60 °C
• Storage Temperature: ‑40 °C ~ +85 °C
• Protection Class: IP20 open‑chassis unit, install inside control cabinet
• System Compatibility: Fan, pump, conveyor three‑phase motor local start‑stop control
• Diagnostics: Overload trip indicator, contact status feedback via auxiliary contacts
• Humidity: 5‑95 % RH non‑condensing
• Weight: 2.4 kg
• Dimensions: NEMA Size 0 motor‑starter footprint
•

Product Overview

709‑CAB SER‑P is legacy NEMA‑style full‑voltage motor starter assembly. It integrates main contactor and thermal overload relay for direct‑on‑line three‑phase motor starting and overload protection. Widely used in old‑generation factory motor‑control cabinets. Surplus and refurbished tested spare starter for legacy‑automation‑system retrofitting and maintenance projects.

Application Notes

‑ Set overload current dial according to motor nameplate rated current. ‑ Verify coil voltage matches control‑circuit supply voltage before power‑on. ‑ Typical deployment: NEMA Size 0 motor‑starter spare‑part stocking.
