1. Product Title

BENTLY NEVADA 1701/15‑ FieldMonitor Proximitor Input Monitor Module

2. Product Overview

The 1701/15 is FieldMonitor series proximitor input monitor module by Bently Nevada, designed for eddy‑current proximity probe signal conditioning for rotating‑machinery protection systems. It receives raw displacement signals from proximity probes, executes amplification, linearization and filtering, outputs standardized 4‑20 mA analog signal and supports Modbus‑RTU RS485 communication. Equipped with relay alarm outputs for shaft displacement monitoring of turbines, compressors and large rotating equipment. Rugged enclosure adapts to harsh field installation environment, realizing real‑time shaft position monitoring and early fault warning for critical rotating assets.

3. Technical Specifications

• Brand: BENTLY NEVADA
• Model: 1701/15
• Warranty: One Year
• Condition: 100% New & Original
• Type: Proximitor input monitor for eddy‑current probes
• Power Supply: 9‑32 VDC, nominal 24 VDC
• Output: 4‑20 mA analog; RS‑485 Modbus‑RTU; 2 Form‑C relay outputs
• Operating Temp: -40 °C ~ +70 °C
• Compatibility: 3300XL proximity probes, 3500 monitoring system series
• Mounting: DIN‑rail or enclosure mounting
•

4. Application Scenarios

• Steam Turbine Monitoring: Shaft radial displacement monitor for power‑plant turbine units.
• Compressor Skid Protection: Proximity signal conditioning for petrochemical plant critical compressors.
• Rotating‑Machinery Condition‑Monitoring: Field‑mounted signal‑processing unit for large‑pump and fan shaft‑position surveillance.
