1. Product Title
Bently Nevada 330180-91-05 – 3300 XL Proximity Sensor Extension Cable
2. Product Overview
The 330180-91-05 is a dedicated extension cable belonging to Bently Nevada’s industry-standard 3300 XL eddy current proximity transducer system. It serves as the critical transmission medium connecting the proximity probe and the vibration monitoring system’s front-end interface module, transmitting high-frequency displacement signals generated by the non-contact eddy current probe in rotating machinery condition monitoring systems. This component resolves wiring distance limitations between on-machine probes and control room rack-mounted monitoring equipment, maintains stable impedance matching throughout the signal loop, and minimizes electromagnetic interference and signal attenuation during long-distance transmission. Reliable signal delivery from 330180-91-05 directly guarantees the accuracy of shaft vibration, axial thrust position and rotor eccentricity measurements, effectively preventing false alarms and measurement deviations in turbine and rotating equipment protection loops.
3. Technical Specifications
- Brand: Bently Nevada
- Model: 330180-91-05
- Warranty: One Year
- Condition: 100% New & Original
- Series Compatibility: Matches 3300 XL 8mm proximity probe series
- Impedance Characteristic: Calibrated 50-ohm system impedance for full loop matching
- Connector Type: Hermetically sealed threaded metal connectors at both ends
- Operating Temperature: -40°C to +105°C, suitable for harsh industrial field environments
- Shielding Structure: Double-layer braided shielding to suppress EMI/RFI interference
- Insulation Material: High-temperature, oil-resistant fluoropolymer outer jacket
- Length Specification: Factory fixed length defined by suffix code 91-05
- Protection Rating: Resists vibration, mechanical abrasion, lubricating oil and chemical splashes
4. Application Scenarios
- Thermal Power Generation Plants: Deployed on steam turbines, generator rotors and boiler feed water pumps to extend probe wiring for shaft vibration and thrust bearing position continuous monitoring.
- Oil & Gas Refineries & Petrochemical Plants: Used on centrifugal compressors, gas turbines and process pumps to transmit eddy current signals for rotating equipment health protection and trip interlock control.
- Metallurgy & Heavy Industrial Rotating Equipment: Installed on large industrial blowers, fans and high-speed rotary machinery to ensure long-distance signal integrity for predictive maintenance and machinery protection systems.
