ELAU (Schneider) SM-070/60/010/P1/45/S1/B0 Synchronous Brushless Servo Motor

Basic Technical Specifications

• Full Model: SM-070/60/010/P1/45/S1/B0
• Brand: ELAU
• Warranty: One Year
• Power Supply: 400V three-phase AC servo drive power
• Rated Speed: 6000 rpm maximum continuous speed
• Rated Torque: 1.1 Nm continuous torque, peak torque up to 7.2 Nm
• Rated Current: 6.0 A nominal operating current
• Frame Size: 70mm square flange mounting (SM070 frame)
• Encoder Configuration: S1 = 24-bit single-turn high-resolution absolute encoder
• Shaft & Brake: P1 = solid output shaft, B0 = without holding brake
• Protection Class: IP65 for flange and shaft end, IP54 for motor housing
• Insulation Class: Class F
• Operating Temperature: -20°C ~ +60°C, non-condensing environment
• Cooling Mode: Natural convection air cooling
• Weight: Approx 2.74kg
• Certifications: CE, UL, cUL industrial safety certification
•

Product Overview

The SM-070/60/010/P1/45/S1/B0 is a compact high-speed permanent magnet synchronous servo motor developed by German ELAU, fully matched with ELAU PacDrive or Schneider Lexium servo drive systems. It adopts low-inertia rotor design to deliver ultra-fast acceleration and deceleration response, supporting high-precision closed-loop position, speed and torque control.

The 24-bit absolute single-turn encoder eliminates zero-point homing after power cycle, greatly simplifying equipment startup logic and avoiding positioning deviation caused by power failure. The fully sealed IP65 front flange resists liquid splashing, dust and cleaning fluid erosion, which is critical for food, pharmaceutical and packaging machinery washdown environments.
