Description

Emerson VE4001S2T2B4 32-Channel High Density Dry Contact Discrete Input Module

Technical Specifications

• Product Model: VE4001S2T2B4
• Brand: Emerson (DeltaV Distributed Control System)
• Warranty: One Year
• Input Voltage: 12VDC DeltaV LocalBus backplane power; 24VDC dry contact field sensing voltage
• Operating Temperature: -40°C ~ +70°C continuous full-load operation
• Storage Temperature: -40°C ~ +85°C
• Response Time: Deterministic millisecond-level channel scanning cycle, fast contact state detection
• Protection Class: IP20 when installed inside DeltaV standard control cabinet
• Accuracy Class: Digital on/off state zero error acquisition, 2500V RMS reinforced galvanic isolation rating
• Output Frequency: No analog output, fixed DeltaV LocalBus internal bus communication rate
• Rated Current Range: Max 200mA backplane consumption, total power consumption ≤5W
• Communication Interface: DeltaV proprietary LocalBus rack backplane bus
• Supported Protocols: DeltaV LocalBus internal I/O communication protocol
• Overload Capacity: Per-channel electrical isolation, open-circuit wire break detection, ESD protection, surge suppression, single-channel fault locking to avoid module cascading failure
• Dimensions: 118mm × 70mm × 30mm, single-slot DeltaV S-series rack plug-in module footprint
•

Product Overview

The Emerson VE4001S2T2B4 is a high-density 32-channel digital discrete input module exclusively developed for Emerson DeltaV S-series DCS platform. It is designed to collect potential-free dry contact switch signals from field equipment, including limit switches, emergency stop buttons, valve position feedback switches, relay auxiliary contacts, flow/pressure switch trip signals and safety interlock contacts, then convert field on/off status into digital data and upload to DeltaV controllers for logic interlock, equipment status monitoring, alarm triggering and safety shutdown protection.

This high-density DI module solves cabinet space waste and low I/O expansion efficiency problems for large-scale process control systems. It integrates 32 independent input channels into one single rack slot, greatly reducing the total number of I/O racks, wiring terminals and spare part inventory compared with low-density 16-channel cards. Each channel adopts isolated circuit design to block ground loop interference and voltage surges transmitted from field heavy-load equipment, effectively protecting the DeltaV backplane and core controller from electrical damage. Built-in comprehensive self-diagnosis function can automatically identify field wire breakage, loose wiring and channel hardware faults, push alarm information to DeltaV operator workstation for rapid troubleshooting. The hot-swappable pluggable structure supports online replacement without powering down the entire DCS rack, minimizing unplanned production downtime during maintenance and system upgrade.
