Description

EPRO PR6423/30J‑1001 Eddy‑Current Proximity Sensor

Technical Specifications

• Product Model: PR6423/30J‑1001
• Brand: EPRO (Emerson AMS Turbomachinery Monitoring System)
• Warranty: One Year
• Matching Converter: CON021 / CON031 eddy‑current signal converter (required for complete measuring chain)
• Sensor Probe: 8 mm diameter probe, M10×1 mounting thread, stainless‑steel housing, PEEK sensing tip
• Scale Factor: 8 V/mm nominal sensitivity, linear measuring range 0‑2 mm, initial installation air‑gap 0.5 mmEmerson
• Frequency Response: DC‑20 kHz (−3 dB), captures high‑speed shaft vibration and transient displacement signals
• Operating Temperature: Probe head −35 °C ~ +180 °C; armored cable −35 °C ~ +150 °C
• Storage Temperature: −40 °C ~ +180 °C
• Protection Class: IP66, fully armored PTFE‑insulated shielded cable, oil‑resistant, anti‑vibration constructionEmerson
• Cable Configuration: 5‑meter total armored cable length, open bare wire termination (suffix‑1001 coding)Emerson
• Measurement Target: Minimum 25 mm shaft diameter, calibrated for ferromagnetic steel shaft materialEmerson
• Accuracy: Non‑linearity ≤ ±0.025 mm within working range, stable long‑term drift performanceEmerson
• Application Signal: Non‑contact measurement of shaft radial vibration, axial thrust displacement, shaft position and eccentricity
• System Compatibility: Directly compatible with AMS‑6500, MMS6000 monitoring racks
• Certifications: CE compliance, certified for turbomachinery heavy‑duty industrial environments
•

Product Overview

The PR6423/30J‑1001 is a high‑performance 8 mm eddy‑current proximity probe for EPRO/Emerson turbomachinery protection systems. Together with external CON021 or CON031 converter, it forms a complete non‑contact displacement measuring chain for critical rotating equipment.

The probe detects real‑time clearance variation between probe tip and rotating metal shaft by eddy‑current principle. It monitors radial shaft vibration, axial thrust position, shaft eccentricity and thermal expansion without physical contact, avoiding mechanical wear and signal distortion. The heavy‑duty armored cable withstands high temperature, oil splash and strong vibration typical inside turbine casings and compressor enclosures.
