GE PCIE-5565PIORC-100000 Reflective Storage Memory Card
PCIE-5565PIORC-100000
The GE PCIE-5565PIORC-100000 stands out for its ability to handle simultaneous high-speed data acquisition across all 16 channels without compromising accuracy. Unlike lower-performance cards that multiplex channels—introducing timing delays—this unit’s parallel architecture ensures every sensor signal is sampled at 1 MS/s, critical for capturing transient events like motor startups or power grid faults. Its 16-bit resolution captures subtle signal variations, from microvolt-level noise in precision sensors to large voltage swings in industrial machinery, eliminating the need for external signal conditioning in many applications.
For more information, please click on the following link:
|
Label
|
Specification
|
|
Model Number
|
PCIE-5565PIORC-100000
|
|
Brand
|
GE
|
|
Type
|
PCI Express Industrial Data Acquisition Card
|
|
Interface
|
PCIe x4 (Gen 3)
|
|
Analog Inputs
|
16 differential channels
|
|
Sampling Rate
|
1 MS/s per channel (simultaneous sampling)
|
|
Resolution
|
16-bit
|
|
Input Range
|
±10V, ±5V, ±2.5V (software-configurable)
|
|
Digital I/O
|
8 bidirectional channels
|
|
Operating Temp
|
-40°C to +70°C
|
|
Power Requirement
|
7.5W (from PCIe slot)
|
|
Certifications
|
CE, UL, RoHS
|
|
Dimensions
|
167mm (L) x 112mm (W) (standard PCIe full-height)
|
|
Synchronization
|
IEEE 1588 PTP, hardware trigger input
|
|
Compatible OS
|
Windows, Linux (RTOS support optional)
|
The GE PCIE-5565PIORC-100000 stands out for its ability to handle simultaneous high-speed data acquisition across all 16 channels without compromising accuracy. Unlike lower-performance cards that multiplex channels—introducing timing delays—this unit’s parallel architecture ensures every sensor signal is sampled at 1 MS/s, critical for capturing transient events like motor startups or power grid faults. Its 16-bit resolution captures subtle signal variations, from microvolt-level noise in precision sensors to large voltage swings in industrial machinery, eliminating the need for external signal conditioning in many applications.
GE offers several complementary products to extend the GE PCIE-5565PIORC-100000’s capabilities:
PCIE-5565PIORC-200000 – A 32-channel variant for high-density data acquisition applications, compatible with the same software suite.
PCIE-5561PIORC-100000 – A lower-channel (8) model with enhanced 24-bit resolution for ultra-precision measurements.
GE DAQmx Software – Configuration and data logging tools optimized for the PCIE-5565PIORC-100000’s architecture.
PCIE-5565PIORC-100001 – A ruggedized version with extended shock and vibration resistance for mobile testing.
GE Signal Conditioning Modules – External amplifiers and isolators for harsh-environment sensors paired with the card.
PCIE-5570PIORC-100000 – A mixed-signal card with additional digital output channels for control applications.
GE Edge Gateway – A device that bridges the PCIE-5565PIORC-100000 to cloud platforms for remote monitoring.
