Honeywell FC-SDIL-1608 Safety Digital Input Module
FC-SDIL-1608 is a 16-channel safety digital input module for the Honeywell Safety Manager (FSC) system. It supports NAMUR standard loop monitoring and is used for signal acquisition in SIL2/SIL3 safety instrumented systems (SIS).

The product images shown are not actual photos. There are still more models that have not been launched yet.For more details or price negotiations, please contact us: Email: sales@fyplc.cn | WhatsAPP: +86 15359458915

Core Product Information
Brand: Honeywell
Model: FC-SDIL-1608 (Common Version V1.2/V1.3)
Number of Channels: 16 isolated digital inputs
Input Signals: 5/24VDC, compatible with NAMUR (DIN 19234) standard, with 8V loop power supply
Safety Level: SIL2/SIL3 (IEC 61508/61511)
Function Configuration: Configurable 8 standard + 8 latch inputs, or 16 latch inputs
Diagnostic Capabilities: Open circuit, short circuit, grounding fault detection, channel-level self-diagnosis
Operating Temperature: -40°C ~ +70°C
Size / Weight: Standard DIN rail module, approximately 48.2×48.2×30.5mm / 0.5kg
Compatible Systems: Honeywell Safety Manager (FSC) / TDC3000
Status Indicators: LED indicators, showing channel/module status

Key Features
Safety Loop Monitoring: Each input has loop monitoring, capable of detecting on-site line open circuit / short circuit, suitable for safety-critical circuits.
Latching Function: Key channels can latch pulse signals (such as valve action), requiring manual / logical reset, facilitating accident traceability.
High Integrity Design: Dual voltage compatibility (5/24VDC), optically isolated, strong anti-interference, suitable for high-risk scenarios such as chemical and power industries.
System Integration: Communicates with FSC controller through fault-tolerant backplane bus, supports real-time safety logic processing.
Typical applications:
Petrochemical industry: Emergency shutdown (ESD) system of SIS, flame/gas detection signal acquisition.
Power industry: Safety monitoring of power plant boilers / steam turbines, interlock protection of substations.
Process industry: Switch quantity monitoring of water treatment, pharmaceuticals, metallurgy, etc. for safety instrument systems.
