PXI‑6512 Bank‑Isolated Digital Output Module

Technical Specifications

• Product Model: PXI‑6512
• Brand: National Instruments (NI)
• Warranty: One Year
• Form Factor: Standard 3U PXI single‑slot module
• Power Supply: Powered via PXI chassis backplane
• Operating Temperature: 0 °C ~ +55 °C
• Storage Temperature: ‑40 °C ~ +70 °C
• Response Time: Typical propagation delay 75 μsdocs-be.ni…
• Protection Class: IP20, chassis‑internal assembly
• Accuracy Class: Industrial isolated digital I/O grade
• Output Frequency: Not applicable
• Channels: 64‑channel optically isolated source digital outputs, 8 isolated banksNI
• Max Switching Voltage: ±30 VDC per channel
• Per‑Channel Current: 75 mA continuous per line at 25 °C; 350 mA single‑channel max derateddocs-be.ni…
• Special Features: Programmable power‑on output states, digital watchdog for fail‑safe condition, software‑selectable input filter for debounceNI
• Connector: 100‑pin female D‑sub external I/O connector
• Software Compatibility: NI‑DAQmx driver, LabVIEW, LabWindows/CVI, Python / C / .NET API support
• Diagnostics: PXI bus link and module health LED indicators
• Humidity: 10‑90 % RH non‑condensing
• Weight: 0.34 kg
• Dimensions: Standard 3U PXI single‑slot footprint
•

Product Overview

PXI‑6512 is bank‑isolated industrial digital output module for PXI test‑and‑measurement platforms. It delivers 64 isolated source‑type digital outputs grouped into eight galvanically separated banks, protecting PXI host hardware from field‑side ground loops and voltage transients. Integrated watchdog function forces pre‑configured safe output levels upon software or host failure, critical for test‑stand safety interlock control. Widely deployed for manufacturing test systems, hardware‑in‑the‑loop simulation and industrial‑equipment validation setups. Surplus and refurbished tested spare DAQ hardware for test‑system maintenance and upgrade projectsNI.

Application Notes

‑ Install inside compliant PXI chassis; complete NI‑DAQmx driver installation before commissioning. ‑ Use shielded 100‑pin accessory cables for field‑signal wiring. ‑ Configure watchdog safety parameters within software before connecting actuators. ‑ Typical deployment: PXI‑based test‑system isolated digital‑output spare‑part stocking.
