Description

DKC01.3‑100‑7‑FW

1. Product Title

Rexroth Indramat DKC01.3‑100‑7‑FW‑ ECODRIVE03 High‑Power Servo Drive Controller

2. Product Overview

DKC01.3‑100‑7‑FW belongs to Rexroth Indramat ECODRIVE03 Type3 servo drive family, a high‑power single‑axis servo controller for heavy‑duty industrial motion applicationsIndramat P…. It supports modular I/O interface cards and external firmware module for convenient function reconfiguration, delivering full‑digital torque, speed and position closed‑loop control. Compatible with resolver and incremental encoder motor feedback signals. Comprehensive protection covers over‑current, over‑voltage, over‑temperature and short‑circuit conditions. This discontinued high‑current drive is critical maintenance spare for large‑format machine‑tools, metal‑forming presses and heavy automated production lines.

3. Technical Specifications

• Brand: Rexroth Indramat
• Model: DKC01.3‑100‑7‑FW
• Warranty: One Year
• Condition: 100% New & Original
• Series: ECODRIVE03 Type3
• Max Output Current: 100 A
• Feedback: Resolver, incremental encoder
• Feature: Modular I/O card, external firmware module
• Protection: OCP, OVP, thermal shutdown, short‑circuit protection
• Communication: Serial service interface
• Operating Temp: 0 °C ~ +55 °C
• Mounting: Vertical cabinet chassis‑mount
• Protection Class: IP20
•

4. Application Scenarios

• Heavy‑duty Metal‑forming Machine‑tool Cabinet: High‑power servo‑drive spare for ECODRIVE03 motion axes.
• Large Automated Press & Handling Production‑line: Replacement amplifier for heavy‑load positioning axes.
• Legacy Indramat ECODRIVE System Maintenance: Drop‑in spare for installed DKC01.3 series servo‑drive hardware.
