Description

RMBA-01 Modbus RTU Fieldbus Adapter Module

Technical Specifications

• Product Model: RMBA-01
• Brand: ABB
• Warranty: One Year
• Input Voltage: Powered internally by ACS800/DCS800 drive control board 24 VDC bus supply
• Operating Temperature: 0°C to +55°C
• Storage Temperature: -40°C to +85°C
• Response Time: ≤ 20ms Modbus RTU polling data response
• Protection Class: IP20 (internal cabinet plug-in installation)
• Accuracy Class: N/A (Communication interface module)
• Output Frequency: Digital serial communication, no AC power output
• Rated Current Range: Max 30mA internal module power consumption
• Communication Interface: Galvanically isolated RS485 4-pin detachable terminal block
• Supported Protocols: Modbus RTU only, CiA DSP 402 drive device profile
• Overload Capacity: Built-in ESD protection, bus short-circuit automatic locking protection
• Dimensions: 263mm × 58mm × 28mm drive option slot form factor
•

Product Overview

The RMBA-01 is a dedicated plug-in fieldbus communication adapter developed by ABB exclusively for ACS800 and DCS800 series industrial variable frequency drives, serving as the protocol conversion gateway between ABB inverters and upper-level Modbus-based automation systems. This compact option board inserts directly into the drive’s RMIO control card expansion slot, converting native drive internal communication signals into standard Modbus RTU serial data to enable centralized parameter configuration, real-time speed/torque feedback, fault code reading and start-stop command execution from PLC, SCADA or HMI hosts. It resolves core integration obstacles including incompatible drive proprietary bus protocols, signal interference on long-distance field wiring, limited multi-drive synchronous control capability, and tedious on-site manual parameter setup for multi-unit drive arrays. Drive system technicians, automation integrators, plant electrical maintenance engineers and process control designers across material handling, water treatment, HVAC, mining and pulp processing industries gain streamlined system connectivity with this ABB communication module. The isolated RS485 circuit eliminates ground loop noise in electrically noisy factory environments, while configurable DIP switch bus termination ensures stable transmission over the maximum 1200-meter Modbus cable length.
