1. Product Title
Siemens 6SL3120-1TE24-5AC0 – SINAMICS S120 Booksize Single Motor Module
2. Product Overview
The Siemens 6SL3120-1TE24-5AC0 is a booksize single motor module within the modular SINAMICS S120 drive platform. Powered by a shared DC link bus, it converts DC voltage into variable-frequency three-phase AC power to drive synchronous servo motors and asynchronous motors. The 6SL3120-1TE24-5AC0 delivers high dynamic motion performance with optimized pulse sampling, and supports extended Safety Integrated functions for machine safety requirements. Communication with the control unit is realized via DRIVE-CLiQ digital interface. Built-in protective monitoring prevents overload, short-circuit and over-temperature faults, ensuring stable precision motion control for automated machinery in continuous production environments.
3. Technical Specifications
- Brand: Siemens
- Model: 6SL3120-1TE24-5AC0
- Warranty: One Year
- Condition: 100% New & Original
- Series: SINAMICS S120 Booksize Drive
- Frame Size: C-Type Booksize
- DC Link Input: 510 V – 720 V DC
- Rated Output: 3AC 400 V, 45 A
- Base Load Current: 38 A
- Cooling: Internal air cooling
- Communication: DRIVE-CLiQ interface
- Pulse Frequency: 4 kHz
- Supported Motors: Synchronous servo motors, asynchronous motors
- Safety Functions: Extended Safety Integrated
- Operating Temp: 0 °C to +40 °C (derating required above 40°C)
- Mounting: Vertical cabinet rack installation
- Protection Functions: Overcurrent, overvoltage, thermal, short-circuit protection
- Scope of Supply: Integrated DRIVE-CLiQ cable+
5. Application Scenarios
- CNC Machine Tools: Servo feed axis and spindle control for machining centers and lathes.
- Automated Assembly Equipment: Multi-axis positioning control for robotic handling and transfer systems.
- Plastics Processing Machinery: Precision torque and speed regulation for injection molding and extrusion lines.
