Description
Technical Specifications
- Product Model: DVSC-TT-14C-09
- Brand: Vision (DN Solutions / Doosan)
- Warranty: One Year
- Input Voltage: AC 200 ~ 230 V, 50 / 60 Hz
- Operating Temperature: 0°C ~ +50°C
- Storage Temperature: -20°C ~ +70°C
- Response Time: < 1 ms position loop response
- Protection Class: IP20 (control panel mounting)
- Accuracy Class: ±0.01° positioning repeatability
- Output Frequency: 0 ~ 400 Hz
- Rated Current Range: 14 A RMS continuous output
- Communication Interface: PCN1, PCN2 encoder ports; I/O terminal bus
- Supported Protocols: Pulse train input, analog command, serial servo communication
- Overload Capacity: 300% rated current for 3 seconds
- Dimensions: 150 mm × 85 mm × 190 mm
Product Overview
The Vision DVSC-TT-14C-09 is a high-performance AC servo drive engineered for precise motion control on machine tools and automated production equipment. This servo amplifier delivers three control modes – position, speed and torque – to match the dynamic requirements of rotary servo motors compatible with the Vision motion platform. It resolves unstable positioning and vibration issues seen on older drive hardware during high-speed cyclic operation, with built-in anti-vibration filtering and auto-tuning functions to simplify commissioning. Machine builders, CNC maintenance technicians and automation system integrators benefit from integrated fault diagnostics, a front-mounted digital operator panel and robust short-circuit, overvoltage and overheat protection. The unit is designed as a direct replacement for matching series drives on Doosan machine platforms, minimizing rework during equipment overhaul and retrofitting projects.
Application Scenarios
- CNC Machining Center Axis Control: Deployed to drive linear and rotary feed axes on milling and turning equipment. Fast loop response maintains consistent contour accuracy during high-speed cutting and reduces surface defects on finished workpieces.
- Automated Assembly Transfer Lines: Controls servo actuators for pick-and-place stations, indexing tables and conveyor positioning. Tunable torque limits prevent mechanical collision damage during part handling cycles.
- Metal Forming & Press Auxiliary Motion Systems: Executes synchronized positioning for feeders and material handling units. Short-duration overload capability supports peak load conditions during rapid stroke movements.
- Retrofit of Legacy Doosan Machine Tools: Used as a drop-in replacement for ageing servo drives on existing machining equipment. Matching mechanical footprint and wiring layout shortens machine downtime during maintenance upgrades.
