Description

Y4550220‑0100 Terminal Cable Assembly

Technical Specifications

• Product Model: Y4550220‑0100
• Brand: GE Vernova
• Warranty: One Year
• Input Voltage: Low‑voltage signal‑level cable
• Operating Temperature: ‑20 °C ~ +70 °C
• Storage Temperature: ‑40 °C ~ +85 °C
• Response Time: Passive wiring assembly
• Protection Class: IP20 internal rack‑use cable
• Accuracy Class: Passive signal transmission cable
• Output Frequency: Not applicable
• Rated Current: Signal‑level low‑current rating
• Function: Pre‑fabricated multi‑conductor signal cable assembly for Mark VIe system, connects I/O pack and terminal‑base hardware
• Construction: Shielded twisted‑pair internal control‑rack cable, custom‑length assembly
• System Compatibility: GE Mark VIe turbine‑control rack internal wiring
• Termination: Factory‑crimped dedicated multi‑pin connectors on both ends
• Humidity: 5‑95 % RH, non‑condensing
• Weight: 0.35 kg
• Dimensions: Factory‑defined fixed‑length cable harness
•

Product Overview

Y4550220‑0100 is original factory pre‑assembled shielded signal cable harness for GE Mark VIe turbine‑control racks. It establishes reliable signal interconnection between I/O pack modules and corresponding terminal‑base boards inside control cabinet. Shielded construction reduces EMI noise interference for low‑level analog and discrete signals. Factory‑terminated connectors guarantee correct pin‑assignment and avoid field‑wiring error. Critical spare harness for cabinet disassembly, rebuild and maintenance work.

Application Notes

‑ Only apply inside Mark VIe control cabinet; not for field external wiring. ‑ Avoid sharp bending and mechanical pulling force on cable harness. ‑ Verify connector pin‑alignment before plug‑in. ‑ Typical deployment: power‑plant Mark VIe rack‑cable‑harness spare‑part stocking.
