ABB 3AXD50000749034 (IGBT Module Kit)
3AXD50000749034 is an IGBT power module kit of ABB’s drive system. Its model is BGAD-21C/300A/1700V and is compatible with medium and high voltage frequency converters. It is used for motor drive and power conversion.

The product images shown are not actual photos. There are still more models that have not been launched yet.For more details or price negotiations, please contact us: Email: sales@fyplc.cn | WhatsAPP: +86 15359458915

Basic Information
Brand: ABB
Material Number: 3AXD50000749034
Module Model: BGAD-21C
Type: (including driver board + power device)
Rated Current: 300 A
Rated Voltage: 1700 V
Packaging Characteristics: EP+ insulation, TIM FOIL heat-conductive film, with shielding cover
Applicable Models
ACS800 Series: Medium Voltage / High Power Frequency Converters (such as ACS800-704, etc.)
ACS880 Series: High Power Drive Units
Industrial Motor Drives, Fans / Pumps / Compressors and other Heavy Load Applications
Core Parameters
IGBT Specifications: 1700V/300A, Low Loss Slot-Type
Heat Dissipation Interface: With TIM Heat Conductive Film, Reduces Thermal Resistance
Insulation Grade: EP+ Enhanced Insulation, Resistant to Arc
Driver Integration: Built-in Gate Driver and Protection Circuit (Overcurrent / Overvoltage / Overheat)
Weight: Approximately 2.5 kg

Key Features
High Reliability: 1700V voltage rating is compatible with medium-voltage power grids, suitable for harsh working conditions.
Integrated Design: Module + driver board integrated, simplifying replacement and maintenance.
Efficient Heat Dissipation: Standardized heat-conducting film is equipped to enhance heat dissipation efficiency and reduce temperature rise.
Comprehensive Protection: Built-in overcurrent, overvoltage, overheat, and short-circuit protection, responding quickly to faults. Typical application
High-power motor frequency conversion drive in the metallurgy, mining and cement industries
Energy-saving renovation of medium-voltage (≤10kV) fans, pumps and compressors
ABB high-power frequency converter maintenance and replacement of spare parts
Replacement / Compatibility
Compatibility: BGAD-21C series with the same specification modules
Replacement: Applicable to the original model of ABB 3AXD50000749034
