1. Product Title

B&R 8V1022.00-2 – ACOPOS 1022 Series 1kW Modular Servo Drive



2. Product Overview

The 8V1022.00-2 belongs to B&R classic ACOPOS modular servo drive platform, a compact high-precision single-axis motion controller for three-phase 400V class servo motors. It integrates EMC line filter, built-in braking resistor, electronic safe restart interlock inside the housing, greatly reducing external cabinet wiring and safety auxiliary components. Adopting ultra-fast control loop algorithm (50μs servo cycle, 400μs bus communication cycle), it supports high-speed positioning, electronic cam, gantry synchronization and CNC interpolation control. The modular expansion slot design allows free plug-in of encoder feedback modules, EtherCAT/POWERLINK/Ethernet communication cards and digital I/O boards, perfectly matched with B&R X20 PLC, Automation PC and full range synchronous/asynchronous servo motors. This model has been discontinued by the manufacturer, only new surplus and refurbished units available in the market.

3. Core Technical Specifications

• Brad: B&R (Bernecker + Rainer, Austria)
• Model: 8V1022.00-2
• Rated Power: 1 kW
• Main power: 3×400~480V AC ±10%, 50/60Hz
• Control power: 24VDC ±25%
• Max installed apparent power: 3 kVA
• Inrush current (400V): 4A
•

Output Performance

• Continuous output current: 2.2 A
• Peak overload current: 4.4 A (2s maximum)
• Switching frequency: 5~20kHz (default 10kHz)

Built-in Standard Functions

1. Integrated EN 61800-3 C3 grade EMC mains filter
2. Onboard dynamic braking resistor
3. Safe restart inhibit safety circuit
4. DC bus capacitance: 235 µF
