Description

CC-TCNT01 Honeywell C300 Controller IOTA Termination Assembly

Basic Technical Parameters

• Model: CC-TCNT01 (P/N: 51308307-175)
• Brand: Honeywell (Experion PKS DCS System)
• Full Name: C300 Controller Input/Output Termination Assembly (IOTA Backplane Terminal Board)
• Warranty: 1 Year
• Power Supply: 24 VDC, rated operating current 0.311A, power dissipation 2.464W
• Operating Temperature: 0℃ ~ +60℃ continuous working; Storage: -40℃ ~ +85℃
• Protection Class: IP20, internal DCS rack installation, PCB anti-corrosion conformal coating
• Interface Layout:
  1. Dual redundant FTE (Fault Tolerant Ethernet) RJ45 network ports
  2. IO Link bus connector for connection with remote I/O modules
  3. Redundancy sync cable terminal, backup battery interface, time synchronization source port
  4. Vertical gold finger backplane socket for locking with CC-PCNT01 C300 main processor
• Physical Size: 220 × 120 × 53 mm, net weight 0.22 kg
• Overload Protection: Onboard surge suppression, reverse polarity blocking, short-circuit current limit for power and Ethernet circuits
•

Product Overview

The CC-TCNT01 is the dedicated IOTA termination base board exclusively matched with Honeywell CC-PCNT01 C300 core controller, a mandatory bottom carrier component of the Experion PKS distributed control system widely deployed in petrochemical, power generation, oil & gas, chemical and pharmaceutical process industries.

It acts as the central wiring and communication hub between the C300 main CPU and the entire DCS rack subsystem. It distributes 24VDC working power to the controller, integrates all physical cable termination points including redundant FTE control network, I/O expansion bus, controller hot standby synchronization line, memory backup battery and system clock signal wiring.
