Description

Kongsberg DPS232 DGNSS Marine DP Position Reference Processing Unit

Basic Technical Specifications

• Model: DPS232
• Brand: Kongsberg Maritime (Kongsberg Seatex)
• Product Type: Dual GNSS Differential GPS Position Calculation Processor, core reference sensor for ship Dynamic Positioning (DP) system
• Warranty: 1 Year

Electrical Parameters

• Power Input: 100–240 VAC, 50/60Hz, max power consumption 60W (UPS backup recommended)
• GNSS Receiver: GPS L1/L2 + GLONASS L1/L2 multi-constellation, supports SBAS (WAAS/EGNOS/MSAS) differential correction
• Position Accuracy
  1. DGPS/DGLONASS mode: ＜1m (95% CEP), 0.4m (1σ)
  2. SBAS correction mode: ＜1m (95% CEP), 0.6m (1σ)
  3. Commercial high-precision differential service: Up to 20cm absolute positioning
  4. Velocity measurement accuracy: 0.05m/s (95% CEP)
  5.

Mechanical & Environmental

• Chassis: Standard 19-inch rack mount, 2U height
• Dimensions: 485(W) × 88.1(H) × 357–412(D) mm
• Weight: 5.4kg
• Operating Temperature: -35℃ ~ +70℃; Storage: -40℃ ~ +85℃
• Protection: IP20 cabinet indoor installation, fully galvanically isolated serial ports

Interfaces

• Ethernet: 4×RJ45 Gigabit LAN ports for DP system host communication
• Serial Ports: Multiple isolated RS232 / RS422 terminals (compliant with IEC 61162-1 marine standard)
• Expansion: MRU/IMU inertial unit input, 1PPS timing output, analog I/O, relay alarm output, VGA display, USB/PS2 peripheral ports
• Antenna: Matched Novatel GPS-702-GG-N marine GNSS antenna

---

Product Overview

The DPS232 is a professional marine-grade DGNSS differential positioning computing unit developed exclusively for Kongsberg full-series ship DP (Dynamic Positioning) control systems, widely installed on offshore platform supply vessels, FPSO, drilling rigs, dredgers, shuttle tankers and construction barges.

Its core function is to receive multi-satellite constellation signals from the roof GNSS antenna, resolve high-precision absolute geographic coordinates, heading and velocity data, and transmit standardized positioning messages to the DP main controller as one of the primary position reference inputs. In offshore tandem operation (such as FPSO and shuttle tanker oil transfer), it can work with DARPS232 to output centimeter-level relative distance and bearing between two vessels, drastically lowering collision risk during mooring and loading.
