Description

Emerson EPRO MMS6824 Rack Communication Gateway Module

Technical Specifications

• Product Model: MMS6824
• Brand: EPRO (Emerson, Germany), MMS6000 Rotating Machinery Monitoring System series
• Warranty: One Year
• Power Supply: Redundant 18–31.2 VDC DC power input (IEC 61508 Class DC4 standard)
• Operating Temperature: -20°C ~ +60°C
• Storage Temperature: -40°C ~ +85°C
• Response Time: Data polling cycle ≤100ms for full rack module data collection
• Protection Class: IP20 (installed in 19-inch standard industrial control cabinet only)
• Measurement Accuracy: Data transmission error rate ＜0.01%, fully calibrated for vibration and machinery status parameters
• Communication Baud Rate: RS485 EPRO bus: 38400/57600 bps; Modbus RTU: 9600/19200 bps; Front RS232: 9600–115200 bps
• Rated Power Consumption: Max 4.2W total module power draw
• Interfaces
  1. 6-channel RS485 EPRO proprietary bus input (connect up to 31 pcs MMS6000 monitoring modules in one rack)
  2. Modbus RTU output via rear 48-pin blade connector
  3. 10Base-T RJ45 Ethernet port for Modbus TCP/IP transmission
  4. Front panel 6-pin circular RS232 local configuration service port
• Overload Resistance: 2kV isolation between power loop and communication bus, ESD and surge protection for all serial/Ethernet ports
• Mechanical Dimension: Standard Eurocard single-slot rack PCB, fits 19-inch MMS6000 system chassis
•

Product Overview

The MMS6824 is the core rack communication gateway and protocol conversion module for Emerson EPRO MMS6000 turbomachinery protection and condition monitoring system. It serves as the centralized data hub for the entire monitoring rack, aggregating real-time vibration, shaft displacement, speed, bearing temperature, alarm status and fault waveform data from all MMS6000 measurement boards through the dedicated EPRO RS485 fieldbus, then converts the closed proprietary EPRO protocol into universal industry-standard Modbus RTU serial and Modbus TCP/IP Ethernet protocols for upper system access.
