GE 750-P1-G1-S1-HI-A20-R-E – Multilin Feeder Management Relay
Product Overview
The 750-P1-G1-S1-HI-A20-R-E is a high-performance Multilin feeder management relay developed by GE, designed for comprehensive protection, monitoring, and control of medium and low-voltage power distribution feeders. This integrated relay device consolidates multiple power system protection and measurement functions into a compact unit, effectively resolving common power grid operation risks such as overcurrent, ground fault, voltage fluctuation, and frequency deviation. Featuring high-precision signal acquisition, powerful built-in logic algorithms, and multi-protocol communication capability, the 750-P1-G1-S1-HI-A20-R-E ensures safe, stable, and intelligent operation of industrial power distribution systems.
Technical Specifications
-
Brand: GE (General Electric)
-
Model:750-P1-G1-S1-HI-A20-R-E
-
Warranty: One Year
-
Condition: 100% New & Original
-
Product Type: Multilin Feeder Management Protection Relay
-
Rated Frequency: 50 / 60 Hz adaptive operation
-
Input Current: 1A / 5A selectable rated current
-
Analog Inputs: 3-phase current, ground current, 3-phase voltage acquisition
-
Digital Outputs: 6 relay outputs (Form A & Form C contact types)
-
Core Protection Functions: Overcurrent protection, earth fault protection, negative sequence protection, under/over voltage and frequency protection
-
Communication Interfaces: RS232, RS422, RS485 serial ports, optional Ethernet port
-
Supported Protocols: Modbus RTU, DNP3, optional IEC 61850
-
Analog Conversion Range: 0–21 mA standard signal range
-
Operating Temperature: -20°C to +70°C
-
Storage Temperature: -40°C to +85°C
-
Structural Feature: Drawout construction for easy maintenance and replacement
-
Environmental Resistance: Adaptable to dusty, humid and high-interference power station environments
-
Certifications: International industrial power system safety certifications
Application Scenarios
-
Industrial Power Distribution Systems: The 750-P1-G1-S1-HI-A20-R-E is widely deployed in factory low-voltage and medium-voltage feeder cabinets, providing full-range fault protection, real-time electrical parameter monitoring and automatic trip control. It effectively avoids equipment damage and power outage accidents caused by power grid abnormalities.
-
Power Plant & Substation Automation: Applied in industrial substations, distributed power stations and auxiliary power systems. Multi-protocol communication supports seamless connection with SCADA monitoring systems, realizing remote data acquisition, fault recording and intelligent scheduling of power feeders.
-
Petrochemical & Heavy Industry Power Systems: Suitable for high-reliability power supply scenarios in chemical, oil and gas, and metallurgical industries. Multiple protection mechanisms and strong environmental adaptability ensure continuous and safe operation of critical production power supply loops.
