Siemens 6AV2124-0GC01-0AX0 – TP700 Comfort Outdoor HMI Touch Panel
Product Overview
The 6AV2124-0GC01-0AX0 is an industrial-grade TP700 Comfort Outdoor human-machine interface (HMI) from Siemens’ premium Comfort Panel series, specially optimized for harsh outdoor and rugged workshop operating environments. Equipped with a 7-inch high-brightness widescreen TFT display and anti-reflective bonded screen technology, this unit delivers clear visibility even under direct daylight. As a core visualization and operation component for industrial automation, the 6AV2124-0GC01-0AX0 supports real-time process monitoring, parameter configuration, fault diagnosis, and on-site operational control, providing durable and stable human-machine interaction for outdoor industrial control systems.
Technical Specifications
-
Brand: Siemens
-
Model:6AV2124-0GC01-0AX0
-
Warranty: One Year
-
Condition: 100% New & Original
-
Product Series: SIMATIC TP700 Comfort Outdoor Panel
-
Display Size: 7-inch Widescreen TFT LCD
-
Resolution: 800 × 480 Pixels
-
Display Performance: 16 million colors, anti-reflective bonded screen, daylight readable
-
Operation Mode: Capacitive multi-touch operation
-
Operating Voltage: 24V DC
-
Power Consumption: Typical 12W
-
User Memory: 12 MB configuration memory
-
Core Processor: X86 industrial processor
-
Operating System: Windows CE 6.0
-
Communication Interfaces: PROFINET Ethernet, MPI / PROFIBUS DP, USB interface
-
Software Compatibility: Configurable via WinCC Comfort V11 and higher versions
-
Protection Grade: Front IP66, Rear IP20
-
Ambient Adaptability: Designed for outdoor harsh environments, dustproof and rainproof
-
Operating Temperature: Wide industrial temperature range for outdoor scenarios
-
Service Life: Backlight MTBF up to 80,000 hours at 25°C
-
Dimensions (W×H×D): 214mm × 158mm × 67mm
-
Weight: 1.4kg (without packaging)
-
Certifications: CE, ATEX Zone 2 industrial hazardous area certification
Application Scenarios
-
Outdoor Industrial Automation Systems: The 6AV2124-0GC01-0AX0 is specially designed for outdoor unmanned monitoring and on-site operation scenarios, such as outdoor pumping stations, solar energy equipment, and field automation facilities. Its daylight-readable display and IP66 front protection ensure stable operation in wind, dust and variable light conditions.
-
Petrochemical & Onshore Oilfield Equipment: Applied in hazardous industrial zones and open-air production equipment. With ATEX Zone 2 certification and rugged industrial design, it meets the safety and durability requirements of oil and gas field outdoor control and parameter monitoring.
-
Mobile & Field Process Machinery: Widely deployed on large mobile engineering machinery, outdoor processing equipment and field water treatment systems. It supports reliable long-term on-site human-machine interaction and real-time data visualization for non-closed industrial scenarios.
