Description

IS230PCAAH1A Core Analog I/O Pack

Technical Specifications

• Product Model: IS230PCAAH1A
• Brand: GE Vernova
• Warranty: One Year
• Input Voltage: 28 VDC backplane supply
• Operating Temperature: 0 °C ~ +60 °C
• Storage Temperature: ‑40 °C ~ +85 °C
• Response Time: IONet I/O scan ≤1 ms
• Protection Class: IP20 rack‑mount I/O pack
• Accuracy Class: ±0.15 % FS turbine‑control analog grade
• Output Frequency: Not applicable
• Rated Current: 0.70 A @28 VDC consumption
• System Compatibility: GE Mark VIe gas‑steam turbine control system
• Function: Core analog I/O pack, acquires multi‑range 4‑20 mA, ±10 V field analog signals, drives analog output loops; communicates via redundant IONet Ethernet bus
• Diagnostics: Channel open‑loop / short‑circuit detection, front‑panel LED status indicators, module hardware self‑test
• Certifications: CE
• Humidity: 5‑95 % RH, non‑condensing
• Weight: 1.25 kg
• Dimensions: Standard Mark VIe I/O pack footprint
•

Product Overview

IS230PCAAH1A is core analog I/O pack for GE Mark VIe Speedtronic turbine control platform. It interfaces field transmitters, valve positioners and process sensors to the Mark VIe controller through redundant IONet network. It supports hot‑swap replacement and channel‑level fault diagnostics for power‑generation turbine‑control cabinets. Widely deployed on combined‑cycle gas‑turbine and steam‑turbine units. Available as refurbished and new‑old‑stock spare parts for power‑plant control‑rack overhaul.

Application Notes

‑ Install with matched Mark VIe terminal base hardware. ‑ Confirm firmware revision compatibility with main controller. ‑ Strict ESD anti‑static handling during module swap. ‑ Typical deployment: combined‑cycle power‑plant turbine‑control cabinet spare‑part stocking.
