Description

Yokogawa EC401‑50 S3 ESB Bus Coupler Module

Technical Specifications

• Product Model: EC401‑50 S3
• Brand: Yokogawa
• Warranty: One Year
• Input Voltage: 24 V DC (power supplied by host FCU)
• Operating Temperature: 0 °C ~ +55 °C
• Storage Temperature: -40 °C ~ +85 °C
• Response Time: Low‑latency real‑time bus processing
• Protection Class: IP20
• Accuracy Class: Industrial communication grade
• Output Frequency: 128 Mbps ESB bus transmission speed
• Rated Current: 0.5 A typical consumption
• Max Connectable Nodes: Up to 9 units
• Max Transmission Distance: 10 m
• Weight: 0.24 kg
• Dimensions: 130 × 129.5 × 32.8 mm
• Humidity: 5‑95 % RH, non‑condensing

Product Overview

The EC401‑50 S3 is a single‑port ESB Bus Coupler Module built for Yokogawa CENTUM VP distributed control systems. It establishes high‑speed ESB bus links between Field Control Units (FCU) and remote node units, supporting both simplex and dual‑redundant bus configurations for critical process control environments.

This plug‑in coupler enables I/O capacity expansion for FIO‑type field control stations. It handles real‑time I/O data forwarding, bus segment coupling and system diagnostic reporting. Compact hot‑swappable hardware simplifies cabinet‑level maintenance and minimizes plant downtime during module replacement. Standard type without explosion‑proof feature, designed for general industrial control cabinet installation.

Application Notes

• Compatible with Yokogawa FCU series: AFV30S, AFV30D, AFV40S, AFV40D, A2FV50S, A2FV70D and matching ANB‑series node units.
• Dual‑redundant ESB bus is realized by installing two EC401‑50 S3 modules inside one FCU chassis.
• Keep non‑condensing humidity conditions; avoid direct dust and moisture exposure.
• For cabinet‑mount use only; not for direct field hazardous area installation without matched enclosure.
• Used for petrochemical, power generation, pulp‑paper and other large‑scale DCS retrofit & expansion projects.
• Verify firmware compatibility with existing CENTUM VP system before commissioning.
