Description
Technical Specifications
- Product Model: 3500/15 127610‑01
- Brand: Bently Nevada
- Warranty: One Year
- Input Voltage: 85‑264 VAC (universal AC input), 47‑63 Hz
- Operating Temperature: 0 °C ~ +65 °C (32 °F ~ 149 °F)
- Storage Temperature: -40 °C ~ +85 °C (-40 °F ~ 185 °F)
- Response Time: Fast transient voltage correction, <10 ms
- Protection Class: Designed for cabinet‑mount rack installation, over‑voltage, over‑current, short‑circuit protection
- Accuracy Class: Tightly regulated DC output rails ±1 % tolerance
- Output Frequency: DC regulated output
- Rated Current: Max 5.5 A total rack DC power output
- Form Factor: Half‑height rack module, installs in left‑hand dedicated power slots of 3500 rackBaker Hugh…
- Redundancy: Supports dual redundant power configuration (AC‑AC, AC‑DC mixed)
- Hot‑Swap: Hot‑swappable when second power supply is present, no rack shutdown requiredBaker Hugh…
- Humidity: 5‑95 % non‑condensing
- Compliance: IEC 61010‑1, IEC 61326, API 670 system‑level compliant
Product Overview
The Bently Nevada 3500/15 (127610‑01) is a universal AC input power supply module for the 3500 machinery protection rack system. It converts wide‑range alternating‑current mains into multiple stabilized internal DC rails to feed all monitor cards, I/O modules, communication boards and auxiliary circuitry within a complete 3500 rack.
This half‑height unit occupies dedicated power slots on the left side of the 3500 rack. A single unit can power a fully‑populated rack. Two power supplies may be fitted for redundant operation; lower‑slot unit acts as primary, upper‑slot as backup. Hot‑swap capability allows replacement of one power unit while the entire machinery‑protection system remains online, eliminating forced machine trips during power‑supply maintenanceBaker Hugh…. Built‑in fault monitoring reports supply health status to the rack controller for System 1 condition‑monitoring software alarming.
