1. Product Title
Foxboro FBM207B P0914WH‑ 16‑Channel 24VDC Channel‑Isolated Discrete Input Module, I/A‑Series Compact 200 DCS
2. Product Overview
P0914WH (FBM207B) is 24 VDC contact‑sense variant of FBM207 discrete input family for Foxboro I/A‑Series Compact 200 rack. It acquires dry‑contact and 24 VDC digital status from field limit switches, relay auxiliary contacts, motor feedback and safety interlock contacts. Every input channel provides full galvanic channel‑to‑channel isolation to suppress ground loop and field noise. Supports configurable input debounce filtering, sequence‑of‑events (SOE) timestamp recording and pulse‑count function. Hot‑swappable design allows online module replacement without rack power‑down. Front‑panel LED array indicates module health and individual channel status. Matches compression‑type termination assembly for field wiring. It is discontinued EOL hardware, widely used as spare‑part replacement for legacy petrochemical, chemical and power‑plant DCS racks.
3. Technical Specifications
- Brand: Foxboro (Schneider Electric / Invensys)
- Model: FBM207B, part‑number P0914WH
- Warranty: One Year
- Condition: 100% New & Original
- Channels: 16 channel‑isolated discrete input channels
- Input Type: 24 VDC contact‑sense / dry‑contact monitoring
- Isolation: Per‑channel galvanic isolation
- Functions: Configurable input filter, SOE event timestamping, pulse‑count capability
- Diagnostics: Module fault detection; front‑panel LED channel status indicators
- Feature: Hot‑swappable, Compact 200 rack form‑factor
- Matching Termination Assembly: RH916XL
- Operating temperature: ‑40 °C ~ +70 °C
- Humidity: 5‑95 % RH non‑condensing
- Mounting: Slot‑in installation inside Foxboro Compact 200 rack
- Weight: Approx 0.45 kg
- Remark: End‑of‑life product, spare‑part‑only for field‑running I/A‑Series systems
- Compatibility: Foxboro I/A Series DCS system
- Compliance: CE, UL‑cUL certified
5. Application Scenarios
- Chemical Plant DCS Cabinet: Collect on‑off feedback of valves, limit switches, pump auxiliary contacts and local safety interlock signals.
- Petroleum Refinery Automation Rack: Discrete‑status acquisition for fractionation‑unit equipment, capturing relay and ESD‑interlock contact feedback.
- Combined‑Cycle Power‑Generation Facility: Monitor boiler auxiliary equipment, burner‑system and turbine‑auxiliary switch‑contact status for DCS alarming and sequence‑logic execution.
