Description
Schneider Electric ATV930C13N4C Variable Speed Drive
Technical Specifications
- Product Model: ATV930C13N4C
- Brand: Schneider Electric
- Series: Altivar Process ATV930
- Warranty: One Year
- Input Voltage: 3-phase 380–480 VAC (-15% / +10%)
- Operating Temperature: -10 °C to +50 °C (derating required above 40 °C)
- Storage Temperature: -40 °C to +70 °C
- Response Time: < 2 ms torque loop response
- Protection Class: IP00 (cabinet mounting)
- Accuracy Class: ±0.01% steady-state speed regulation
- Output Frequency: 0–500 Hz adjustable; switching frequency 1–8 kHz
- Rated Current Range: 250 A continuous (normal duty); 180 A continuous (heavy duty)
- Communication Interface: Built-in RJ45 Ethernet, Modbus serial terminal
- Supported Protocols: Modbus TCP, Modbus RTU, EtherNet/IP, PROFINET (via option card)
- Overload Capacity: 120% for 60 s normal duty; 150% for 60 s heavy duty
- Dimensions: 650 mm × 320 mm × 243 mm
Product Overview
The ATV930C13N4C is a cabinet-mounted process-grade variable speed drive engineered to control three-phase asynchronous and synchronous motors. It supports 132 kW motor ratings under normal-duty operation and 110 kW for heavy-duty applications without an integrated braking chopper. This drive delivers high-precision torque and speed control, supporting master-slave synchronization for multi-motor process lines. Embedded safety functions including STO, SS1 and SLS mitigate mechanical hazards during equipment faults. Onboard data logging and a built-in web server enable real-time asset monitoring to support predictive maintenance. System integrators and plant maintenance teams deploy this unit to replace aging drives, stabilize process throughput, and reduce energy consumption on continuously operating industrial rotating machinery.
